Xerox Phaser 6280 - Page 445

Phaser 6280 Color Laser Printer Service Manual 7-5
Cleaning and Maintenance
6. Use a Q-tip to clean the clear ADC Sensor’s plastic lens. Clean the area
surrounding the Sensor. Be sure to clean the Sensor’s Cleaning Brush or
Wiper; it is located on the inside of the ADC Sensor Cover.
7. Clean/vacuum loose toner from the interior of the printer.
Lens
Lens Cleaning Pad
s6280-304
