Phaser 6280 Color Laser Printer Service Manual 9-11
Parts List
Parts List 2.1 Tray 2 (1 of 2)
ID No. Name/Description Part Number
1.
Cassette Assy 250 (with 2, PL2.2.1) (Tray 2) 050K58032
2. Cassette Assy Front (with 3, 12-24) (Tray 2 Front Assy)
3. Separator (Retard) Roller Assembly (with 4-11) 675K74930
4. Chute Separator
5. Spring Chute
6. Bearing Separator Left
7. Separator (Retard) Roller MPT
8. Bearing Separator Right
9. Spring Separator 200
10. Holder Separator MPT
11. Plate Separator
12. Roll Pinch Turn
13. Spring Pinch Turn
14. Follower Left
15. Follower Right
16. Arm Left
17. Spring NF MPT
18. Arm Right
19. Housing Base FR 250
20. Plate Assy Bottom
21. Holder Assy MPT Left
22. Cover Front MPT
23. Handle CST (Tray Handle)
24. Actuator Assy MPT (with 25-28) 120K92391
25. Holder Actuator
26. Actuator No Paper MPT
27. Roll Actuator No Paper
28. Spring No Paper
To Next Page
