Xerox Phaser 6280 Service Manual

Phaser 6280 Color Laser Printer Service Manual 9-13
Parts List
Parts List 2.2 Tray 2 (2 of 2)
ID No. Name/Description Part Number
1.
Cassette Assy Rear 250 (with 2-13, 18, 19, 21-33)
2. Plate Assy BTM A4
3. Stopper PB
4. Gear BTM Lock Oneway
5. Shaft PB A4
6. Gear BTM DMP Oneway
7. Gear PB Left
8. Spring BTM Up 250 A4
9. Guide Assy Side Right 250
10. Guide Assy Side Left 250
11. Gear Pinion
12. Holder Assy Separator (with 14-17) 019K09941
13. Cover Retard CST (Tray Retard Cover)
14. Holder Separator
15. Shaft Separator
16. Clutch Friction Separator (Retard)
17. Roll Assy Retard (Separator) (Periodic Replacement Part - per 100K prints)
(consists of 3 pcs and tech sheet)
604K55370
18. Spring Separator
19. Switch Size Set
20. -----
21. Plate Gear Lock 250
22. Guide Assy Tray End 250
23. Actuator Size
24. Housing Base RE 250
25. Actuator Release PB
26. Spring Stopper Gear
27. Gear PB Right
28. Cover BTM Up 250
29. Rack BTM Lock 250
30. Spring BTM Lock
31. Gear BTM Lock Pinion
32. Gear Lever BTM Lock
33. Lever BTM Lock
