Phaser 6280 Color Laser Printer Service Manual 9-15
Parts List
Parts List 3.1 Paper Feeder (1 of 2)
ID No. Name/Description Part Number
1.
-----
2. -----
3. Solenoid Feed MPT (with 4-5) 675K35590
4. Spring Feed MPT
5. Gear MPT
6. Bearing Earth
7. CAM MPT Right
8. Roll Assy MPT (with 7, 9-12, 18) 059K56521
9. Roll Core MPT
10. Roll Assy Feed MPT
11. Pin Dowel
12. Shaft MPT
13. Bearing
14. Chute MPT
15. Sensor Photo (Tray 1 No Paper Sensor) 930W00113
16. Cover Sensor
17. Harness Assy MPT NPP (J282-J2821) - (Harness Kit) 675K74380
18. CAM MPT Left
19. -----
20. Clamp RFC-11V0
99. Kit Roll and Solenoid Feed MPT (with 3-5, 10) 675K68991
To Next Page
