Phaser 6280 Color Laser Printer Service Manual 9-21
Parts List
Parts List 5.1 Xerographics
ID No. Name/Description Part Number
1. Spring ROS (Laser Unit Spring)
2. ROS Assy (with 1x2) (Laser Unit) 062K19530
3. Connector CRUM
4. Sensor Assy CRU (with 5-8) 130K72260
5. Actuator CRU
6. Spring CRU
7. Bracket Actuator
8. Sensor Photo (Print Cartridge Sensor) 930W00113
9. -----
10. Spring CRU Right
11. Spring CRU Left
12. Dispenser Assy 094K92450
13. Bias Assy
14. Spring ESA Roll
15. LED Assy 122K94230
16. Duct Harness Motor
17. HVPS 105K23260
18. Cartridge Assy (Print Cartridge) (K) (Periodic Replacement Part - per 8K prints) 106R01395
Cartridge Assy (Print Cartridge) (K) (Periodic Replacement Part - per 3K prints) 106R01391
Cartridge Assy (Print Cartridge) (K) (Periodic Replacement Part - per 8K prints - DMO) 106R01403
Cartridge Assy (Print Cartridge) (K) (Periodic Replacement Part - per 3K prints - DMO) 106R01399
Cartridge Assy (Print Cartridge) (K)
(Periodic Replacement Part - per 11K prints - Metered prints)
106R01407
19. Cartridge Assy (Print Cartridge) (C) (Periodic Replacement Part - per 6K prints) 106R01392
Cartridge Assy (Print Cartridge) (C) (Periodic Replacement Part - per 2K prints) 106R01388
Cartridge Assy (Print Cartridge) (C) (Periodic Replacement Part - per 6K prints - DMO) 106R01400
Cartridge Assy (Print Cartridge) (C) (Periodic Replacement Part - per 2K prints - DMO) 106R01396
Cartridge Assy (Print Cartridge) (C)
(Periodic Replacement Part - per 11K prints - Metered prints)
106R01404
20. Cartridge Assy (Print Cartridge) (M) (Periodic Replacement Part - per 6K prints) 106R01393
Cartridge Assy (Print Cartridge) (M) (Periodic Replacement Part - per 2K prints) 106R01389
Cartridge Assy (Print Cartridge) (M) (Periodic Replacement Part - per 6K prints - DMO) 106R01401
Cartridge Assy (Print Cartridge) (M) (Periodic Replacement Part - per 2K prints - DMO) 106R01397
Cartridge Assy (Print Cartridge) (M)
(Periodic Replacement Part - per 11K prints 0 Metered prints)
106R01405
21. Cartridge Assy (Print Cartridge) (Y) (Periodic Replacement Part - per 6K prints) 106R01394
Cartridge Assy (Print Cartridge) (Y) (Periodic Replacement Part - per 2K prints) 106R01390
Cartridge Assy (Print Cartridge) (Y) (Periodic Replacement Part - per 6K prints - DMO) 106R01402
Cartridge Assy (Print Cartridge) (Y) (Periodic Replacement Part - per 2K prints - DMO) 106R01398
Cartridge Assy (Print Cartridge) (Y)
(Periodic Replacement Part - per 11K - Metered prints)
106R01406
22. Core (Ferrite Core)
