Xerox Phaser 6280 Service Manual

Phaser 6280 Color Laser Printer Service Manual 9-23
Parts List
Parts List 6.1 Fuser & Exit
ID No. Name/Description Part Number
1.
Chute Assy Exit Out (with 2-9, 17) (attached on PL 01.02.09) 054K35574
2. Spring Pinch Exit Out
3. Roll Pinch Exit
4. Spring Corrugate
5. Roll Corrugate
6. Holder Corrugate
7. Eliminator Exit
8. Spring Chute Out
9. Chute Exit Out
10. Fuser Assy KMY 115V (Periodic Replacement Part - per 100K prints) 675K70591
Fuser Assy KMY 230V (Periodic Replacement Part - per 100K prints) 675K70601
11. Harness Assy Fuser (P171-J17, J47) - 100V/115V - (Harness Kit, Black & White) 675K74380
Harness Assy Fuser (P171-J17, J47) - 200V - (Harness Kit, Blue & Brown) 675K74380
12. Bracket Fuser
13. Chute Dup Gate 054K40310
14. -----
15. -----
16. -----
17. Plate Earth Exit
18. Lever Fuser D
19. Lever Fuser AD

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
