Phaser 6280 Color Laser Printer Service Manual 9-25
Parts List
Parts List 7.1 Frame
ID No. Name/Description Part Number
1.
-----
2. Support Link Left (Kit)
3. Link Left (Kit)
4. -----
5. -----
6. Holder Damper (Kit)
7. Damper Oil (Kit)
8. Spring Support (Kit)
9. -----
10. -----
11. -----
12. Support Link Right (Kit)
13. Link Right (Kit)
14. Foot (with 14 x 4 pcs)
15. -----
16. -----
17. -----
18. Switch Assy Size 110K15270
19. -----
20. -----
21. -----
22. Spring Tray Lock
23. Duct Side Left
24. Stopper Frame Left
25. Clamp Locking
26. Holder Damper H
27. Damper Oil H
97. Kit Link Left (with 2, 3, 6-8) 675K74280
98. Kit Link Assy Right (with 8, 12-13, 26-27) 675K74290
99. Kit Foot Assy (with 14 x 4 pcs) 675K69770
To Next Page
