Xerox Phaser 6280 Service Manual

Phaser 6280 Color Laser Printer Service Manual 9-29
Parts List
Parts List 9.1 Electrical
ID No. Name/Description Part Number
1.
PWBA EEPROM (XPRO)
2. Varistor
3. Harness Assy Interlock (Interlock Switch-J44) (Harness Kit) 675K74380
4. LVPS KMY 100/115V 105K23641
LVPS KMY 230V 105K23651
5. Edge Saddle ES-0510
6. Edge Saddle LENS-1010
7. -----
8. Clamp RMS-3V0
9. Shield LVPS
10. Fan Main 127E84800
11. Shield Rear
12. -----
13. -----
14. Clamp MST-10V0
15. -----
16. Harness Assy AC IN 110V (Switch Power - J48, J482, FS483,-T484) - (Harness Kit) 675K74370
Harness Assy AC IN 240V (Switch Power - J48, J481) - (Harness Kit) 675K74370
17. Power Cord See Power Cord
Accessories
18. Spacer RCBT-11S
19. Sensor Humidity 130E87990
20. PWBA MCU 960K39343
21. Shield Window
22. Screw Knurling
23. -----
24. -----
25. Shield ESS (I/P Board Shield)
26. -----
27. PWBA ESS (Image Processor Board) (with 35) (with Tech Sheet) 960K39185
28. -----
29. -----
30. 512 MB DDR2 Memory (1x 512 MB) (Option)
604K48400
31. -----
32. -----
33. Clamp RLWC-1SV0
34. -----
35. NVM ROM
36. -----
37. -----
