Xerox Phaser 6280 Service Manual

9-32 Phaser 6280 Color Laser Printer Service Manual
Parts List
Parts List 10.1 Wiring Harness
ID No. Name/Description Part Number
1.
-----
2. -----
3. -----
4. Harness Assy Humidity (J26-J261) - (Harness Kit) 675K74370
5. -----
6. -----
7. -----
8. -----
9. Harness Assy CRU SNR (J19-J191, J192, J193, J194) - (Harness Kit) 675K74370
10. -----
11. -----
12. -----
13. Harness Assy CRUM (J31-J311, J312, J313, J314) - (Harness Kit) 675K74370
14. -----
15. Harness Assy Right Side (J22, J23, J24, J25, J27, J28, J29, J30-J144, J221, J222,
P231, P232, P233, P234, P235, P241, J251, P272, J281, P282, J291, P292, P301) -
(Harness Kit)
675K74370
16. Harness Assy LV Top (J13, J14, J15, J18, J401, J5041-J141, P181, P182, P183, P184,
J40, J501, J502, J504) - (Harness Kit)
675K74370
17. -----
18. Harness Assy IF (J10-J101, J111) - (Harness Kit) 675K74370
19. -----
20. Harness Assy BTM Earth

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
