Xerox Phaser 6280 Service Manual

9-38 Phaser 6280 Color Laser Printer Service Manual
Parts List
Parts List 12.2 Optional 550-Sheet Feeder - Tray 3 (2 of 5)
ID No. Name/Description Part Number
1.
Frame Assy Option
2. -----
3. Harness Assy Feeder Unit (J273-J419)
4. -----
5. Switch Assy Size Option 110K15270
6. PWBA Option Feeder (Tray 3 Feeder Board)
7. Harness Assy C2 Chute (J421-J4211, P4212, P4213)
8. Harness Assy C2 Turn (J420-P4201, P4202)
9. Harness Assy C2 Motor (J422-J4221, J4222)
10. Drive Assy Option Feeder
11. Guide Tray Right 550
12. Guide Tray Assy 550 Left (with 13, 17)
13. Guide Tray Left 550
14. -----
15. Foot PL7.1.99
16. Clamp Mini
17. Spring Tray Lock
18. Clamp Locking
