Xerox Phaser 6280 Service Manual

9-40 Phaser 6280 Color Laser Printer Service Manual
Parts List
Parts List 12.3 550-Sheet Feeder - Tray 3 (3 of 5)
ID No. Name/Description Part Number
1.
Feeder Assy Opt (with 3-11, 13-16, 18, 20-29, 31, 32) 05948273
2. -----
3. Cover Chute
4. Roll Assy Turn
5. Bearing Regi
6. Chute FDR Optional
7. Bearing Regi E
8. Roll Pinch Turn
9. Spring Pinch Turn
10. Chute Assy Bottom
11. Bearing Nudger
12. -----
13. Holder No Sensor
14. Sensor Photo (Tray No Paper Sensor) 930W00113
15. Chute Assy Separator
16. Clamp
17. -----
18. Shaft Feed Optional
19. -----
20. Support Nudger Assy
21. Shaft Nudger
22. Roll Assy Gear Nudger
23. Gear Idler Nudger
24. Holder No Paper Left A4
25. Actuator No Paper A4
26. Holder No Paper Right A4
27. Clutch Oneway Feed
28. Clutch Oneway Nudger
29. Roll Assy Feed (Periodic Replacement Part - per 100K prints) PL2.2.17
30. Harness Assy C2 No Paper (J4212-J42121)
31. Plate Earth Optional
32. Washer

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
