9-44 Phaser 6280 Color Laser Printer Service Manual
Parts List
Parts List 12.5 550-Sheet Feeder - Tray 3 (5 of 5)
ID No. Name/Description Part Number
1.
Tray Assy Rear 550 (with 2-13, 18, 19, 21-34)
2. Plate Assy Bottom A4
3. Stopper PB
4. Gear Bottom Lock Oneway
5. Shaft PB A4
6. Gear Bottom DMP Oneway
7. Gear PB Left
8. Spring Bottom up 550 A4
9. Guide Assy Side Right 550 A4
10. Guide Assy Side Left 550 A4
11. Gear Pinion
12. Holder Assy Separator (with 14-17) PL2.2.12
13. Cover Separator Tray
14. Holder Separator
15. Shaft Separator
16. Clutch Friction Separator
17. Separator (Retard) Roller (Periodic Replacement Part - per 100k prints) PL2.2.17
18. Spring Separator
19. Switch Size Set
20. -----
21. Plate Gear Lock 550
22. Guide Assy Tray End 550
23. Actuator Size
24. Housing Base RE 550
25. Actuator RLS PB
26. Spring Stopper Gear
27. Gear PB Right
28. Cover Bottom Up 550
29. Rack Bottom Lock 550
30. Spring Bottom Lock
31. Gear Bottom Lock Pinion
32. Gear Lever Bottom Lock
33. Lever Bottom Lock
34. Gear 40 Bottom Lock
To Next Page
