Xerox Phaser 6280 Service Manual

10-4 Phaser 6280 Color Laser Printer Service Manual
Plug/Jack and Wiring Diagrams
44 4 E-149 Connects the LVPS and the Interlock Harness.
47 4 E-150 Connects the LVPS and the Fuser Harness.
48 4 E-150 Connects the LVPS and AC IN Harness.
J101 3 F-138 Connects Image Processor Board and Video
Harness.
101 3 F-138 Connects the Image Processor Board and the IF
Harness.
101 4 I-158 Not connected (Debug only).
111 3 F-139 Connects the Image Processor Board and the IF
Harness.
141 3 I-136 Connects the LED Assembly and the Top Low
Voltage Harness.
144 1 C-108 Connects the EEPROM (Belt) and Belt Harness
(Transfer Unit).
144 4 D-153 Connects the EEPROM Board and the Right Side
Harness.
151 2 H-122 Connects the Laser Unit and the Laser Unit Harness.
161 3 G-136 Connects the HVPS and the MCU Board.
171 1 H-106 Connects the Fuser and the Fuser Harness.
181 3 I-139 Connects the Dispenser Assembly (Y) and the Top
Low Voltage Harness.
182 3 H-138 Connects the Dispenser (M) and the Top Low
Voltage Harness.
183 3 H-136 Connects the Dispenser (K) and the Top Low
Voltage Harness.
184 3 H-137 Connects the Dispenser (C) and the Top Low
Voltage Harness.
191 2 H-124 Connects the Print Cartridge Sensor (Y) and the
CRU Sensor Harness.
192 2 H-124 Connects the Print Cartridge Sensor (M) and the
CRU Sensor Harness.
193 2 H-122 Connects the Print Cartridge Sensor (K) and the
CRU Sensor Harness.
194 2 H123 Connects the Print Cartridge Sensor (C) and the
CRU Sensor Harness.
201 1 H-108 Connects the K Drive Assembly (K Mode Sensor)
and the K Sensor Harness.
220 1 F-106 Connects the Control Panel and the Control Panel
Harness.
221 1 H-108 Connects the Main Drive Assembly (Sub Motor) and
the Right Side Harness.
222 1 G109 Connects the Main Drive Assembly (Main Motor)
and the Right Side Harness.
Print Engine Plug/Jack Designators (continued)
P/J Map Coordinates
Remarks
