Xerox Phaser 6280 Service Manual

10-26 Phaser 6280 Color Laser Printer Service Manual
Plug/Jack and Wiring Diagrams
Signal Line Name Description
K MODE SOL ON (L) +24
VDC
On/Off signal of the Color Mode Switching Solenoid.
K MODE SENSED (L) +3.3
VDC
Color mode detects signal of the PH Drive Assembly by
the Photo Sensor (Color Mode Switching Sensor).
MAIN MOT ON Drives control signal of the Main Motor.
MAIN MOT ALARM
MAIN MOT CLK
MAIN MOT LO
MAIN MOT CW/CCW
SUB MOT ON Drives control signal of the Sub Motor.
SUB MOT ALARM
SUB MOT CLK
SUB MOT LO
SUB MOT BRAKE
EXIT CL ON (L) +24 VDC On/Off signal of the Exit Clutch.

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
