10-34 Phaser 6280 Color Laser Printer Service Manual
Plug/Jack and Wiring Diagrams
Signal Line Name Description
Y DISPENSE MOT A Drives control signal of the Dispenser Motor (Y).
Y DISPENSE MOT B
Y DISPENSE MOT XA
Y DISPENSE MOT XB
M DISPENSE MOT A Drives control signal of the Dispenser Motor (M).
M DISPENSE MOT B
M DISPENSE MOT XA
M DISPENSE MOT XB
C DISPENSE MOT A Drives control signal of the Dispenser Motor (C).
C DISPENSE MOT B
C DISPENSE MOT XA
C DISPENSE MOT XB
K DISPENSE MOT A Drives control signal of the Dispenser Motor (K).
K DISPENSE MOT B
K DISPENSE MOT XA
K DISPENSE MOT XB
CARTRIDGE Y SENSED (L)
+3.3 VDC
Detects signal of the CRU (Y) Sensor.
CARTRIDGE M SENSED
(L) +3.3 VDC
Detects signal of the CRU (M) Sensor.
CARTRIDGE K SENSED (L)
+3.3 VDC
Detects signal of the CRU (K) Sensor.
CARTRIDGE C SENSED (L)
+3.3 VDC
Detects signal of the CRU (C) Sensor.
DATA Y IN Controls signal of the CRUM Sensor (Y).
DATA Y OUT
DATA M IN Controls signal of the CRUM Sensor (M).
DATA M OUT
DATA C IN Controls signal of the CRUM Sensor (C).
DATA C Out
DATA K IN Controls signal of the CRUM Sensor (K).
DATA K OUT
To Next Page
