YASKAWA Sigma II Series User Manual

3 Servomotor Specifications and Dimensional Drawings
3.15.3 SGMGH Servomotors (1500 min
-1
) With Standard Backlash Gears and Without Brakes (Foot-mounted Type)
3-88
 Lubrication
• Oil lubricating type (frame numbers: 6130 to 6190)
Servomotors of this type have been shipped with oil removed. Be sure to supply oil until the red line at the upper side
of the oil gauge.
Lubrication oil recommended is industrial-use extreme-pressure gear oil of SP-system, JIS K 2219 industrial-use gear
oil or equivalent. Refer to the following table.
The following shows approximate oil amount to be supplied.
75PAEC6
75PAE76
1APAEB6
1APAEC6
1APAE76
Units: mm (Cont’d)
Model
SGMGH-
Shaft-end Dimensions
S
70
0
0.019–
80
0
0.019–
70
0
0.019–
80
0
0.019–
95
0
0.022–
Surrounding
Air
Temperature
Manufacturer
COSMO Oil
Co., Ltd.
Nippon Oil
Corporation
Idemitsu
Kosan
Co., Ltd.
Showa
Shell
Sekiyu K.K.
Exxon Mobil
Corporation
Japan
Energy
Corporation
0 to 35°C
COSMO
Gear
SE
100, 150
BON-NOCK
M
100, 150
Daphne
Super Gear
Oil
100, 150
Shell Omala
Oil
100, 150
Spartan
EP
100, 150
Mobilgear
627, 629
(ISO VG100,
150)
JOMO
Reductus
100, 150
Units: liter
Frame No.
6130
6135
6140 6160
6170
6175
6180
6185
6190
Horizontal
type
0.7 0.7 1.4 1.9 2.5 4.0
