7.3 Operation in Parameter Setting Mode (Pn)
7-21
7
Digital Operator/Panel Operator
(2) Function Selection Parameters
(a) Types of Function Selection Parameters
Refer to 12.3.2 List of Parameters.
If the parameters with “After restart” in “Setting Validation” column in the table are changed, turn OFF the
main circuit and control power supply and ON again to validate new setting.
• Pn10B.1 and Pn110.0 require the power to be reset as mentioned above.
• Pn10B.0, Pn110.1, and Pn110.2 are enabled with the off-line, so the power does not have to be reset.
* The factory setting is 0001 for the models with 5 kW or more.
Category
Parameter
No.
Name
Factory
Setting
Setting
Validation
Function Selection
Parameter
Pn000 Function Selection Basic Switches
0000 After restart
Pn001 Function Selection Application Switches
0000 After restart
Pn002 Function Selection Application Switches
0000 After restart
Pn003 Function Selection Application Switches
0002 Immediately
Servo Gain Related
Parameter
Pn10B Gain Application Switches
0000
After restart/
Immediately
Pn110 Online Autotuning Switches
0010
After restart/
Immediately
Position Control Related
Parameter
Pn200 Position Control References Selection Switches
0000 After restart
Pn207 Position Control Function Switches
0000 After restart
Torque Control Related
Parameter
Pn408 Torque Function Switches
0000
*
Immediately
Sequence Related
Parameter
(Input Signal Selection)
Pn50A Input Signal Selections
2100 After restart
Pn50B Input Signal Selections
6543 After restart
Pn50C Input Signal Selections
8888 After restart
Pn50D Input Signal Selections
8888 After restart
Sequence Related
Parameter
(Output Signal Selection)
Pn50E Output Signal Selections
3211 After restart
Pn50F Output Signal Selections
0000 After restart
Pn510 Output Signal Selections
0000 After restart
Pn512 Output Signal Reversal Setting
0000 After restart
To Next Page
