YASKAWA Sigma II Series User Manual

2.4 Selecting Cables
2-21
2
Selections
Name Length Type Specifications
Refer-
ence
c
Encoder
Cables
* Applicable for
every type
and capacity.
Cable with loose
wires at encoder end
3 m JZSP-CMP03-03
5.4.4
5 m JZSP-CMP03-05
10 m JZSP-CMP03-10
15 m JZSP-CMP03-15
20 m JZSP-CMP03-20
Cable with connec-
tors on both ends
3 m JZSP-CMP01-03
With an straight plug
5.4.2
5 m JZSP-CMP01-05
10 m JZSP-CMP01-10
15 m JZSP-CMP01-15
20 m JZSP-CMP01-20
3 m JZSP-CMP02-03
With an L-shaped plug
5 m JZSP-CMP02-05
10 m JZSP-CMP02-10
15 m JZSP-CMP02-15
20 m JZSP-CMP02-20
For standard environment
encoder end connector
MS3106B20-29S*
Straight plug
5.4.4
5.5.2
MS3108B20-29S*
L-shaped plug
MS3057-12A*
Cable clamp
For IP67 specification
encoder end connector
JA06A-20-29S-J1-EB
Straight plug
5.5.2
JA08A-20-29S-J1-EB
L-shaped plug
JL04-2022CKE (09)
Cable diameter:
φ
6.5 to
φ
9.5 mm
Cable clamp
JL04-2022CKE (12)
Cable diameter:
φ
9.5 to
φ
13 mm
JL04-2022CKE (14)
Cable diameter:
φ
12.9 to
φ
15.9 mm
SERVOPACK end
connector kit
JZSP-CMP9-1
Soldered
5.5.2
Cables
5 m JZSP-CMP09-05
5.5.2
10 m JZSP-CMP09-10
15 m JZSP-CMP09-15
20 m JZSP-CMP09-20
30m JZSP-CMP19-30
40m JZSP-CMP19-40
50m JZSP-CMP19-50
* Contact DDK Electronics, Inc.
CN2
SERVOPACK end Encoder end
SERVOPACK end Encoder end
SERVOPACK end Encoder end
20 m max.
50 m max.
