YASKAWA Sigma II Series User Manual

12 Appendix
12-46
* 1. The factory setting is 0001 for the models with 5 kW or more.
* 2. The factory setting is 1500 for the models with 5 kW or more.
Pn503
10 min
-1
Speed Coincidence Signal Output
Width
Immediately
Pn504
7 reference
units
NEAR Signal Width Immediately
Pn505
1024
reference
units
Overflow Level Immediately
Pn506 10 ms
Brake Reference-Servo OFF Delay
Time
Immediately
Pn507
100 min
-1
Brake Reference Output Speed Level Immediately
Pn508 500 ms
Timing for Brake Reference Output
during Motor Operation
Immediately
Pn509 20 ms Momentary Hold Time Immediately
Pn50A 2100 Input Signal Selections 1 After restart
Pn50B 6543 Input Signal Selections 2 After restart
Pn50C 8888 Input Signal Selections 3 After restart
Pn50D 8888 Input Signal Selections 4 After restart
Pn50E 3211 Output Signal Selections 1 After restart
Pn50F 0000 Output Signal Selections 2 After restart
Pn510 0000 Output Signal Selections 3 After restart
Pn511 8888 Reserved (Do not change) Immediately
Pn512 0000 Output Signal Reversal Settings After restart
Pn513 0088 Input Signal Selections 5 After restart
Pn51A
0
reference
units
Position Error Level Between Motor
and Load
Immediately
Pn51B
100
reference
units
Reserved (Do not change) Immediately
Pn51C
450 min
-1
Reserved (Do not change) Immediately
Pn51E 0 %
Excessive Position Error Warning
Level
Immediately
Pn600 0 W Regenerative Resistor Capacity Immediately
Pn601 0 W Reserved (Do not change) Immediately
Parameter
No.
Factory
Setting
Name
Setting
Validation
