i.1 Preface
Yaskawa manufactures products used as components in a wide variety of industrial systems and equipment. The selection and application of Yaskawa
products remain the responsibility of the equipment manufacturer or end user. Yaskawa accepts no responsibility for the way its products are incorporated
into the final system design. Under no circumstances should any Yaskawa product be incorporated into any product or design as the exclusive or sole
safety control. Without exception, all controls should be designed to detect faults dynamically and fail safely under all circumstances. All systems or
equipment designed to incorporate a product manufactured by Yaskawa must be supplied to the end user with appropriate warnings and instructions as
to the safe use and operation of that part. Any warnings provided by Yaskawa must be promptly provided to the end user. Yaskawa offers an express
warranty only as to the quality of its products in conforming to standards and specifications published in the Yaskawa manual. NO OTHER WARRANTY,
EXPRESSED OR IMPLIED, IS OFFERED. Yaskawa assumes no liability for any personal injury, property damage, losses, or claims arising from
misapplication of its products.
u
Applicable Documentation
The following manuals are available for V1000 series drives:
STOP
(
Hz
)
(Hz)
(A)
(
V
)
:
:
:
:
:
:
:
:
:
:
V1000
5
400V
V1000 Series AC Drive Installation & Start-Up Manual
Read this manual first. This manual describes installation, wiring, operation procedures, functions, troubleshooting, maintenance,
and inspections to perform before operation.
V1000 Series AC Drive Technical Manual
Read this manual for detailed information about parameter usage. Contact a Yaskawa representative to order this manual.
V1000 Series AC Drive Quick Start Guide
This guide is packaged together with the product. It contains basic information required to install and wire the drive. This guide
provides basic programming and simple set-up and adjustment. Refer to the V1000 Technical Manual for complete descriptions
of drive features and functions.
u
Symbols
Note: indicates a supplement or precaution that does not cause drive damage.
TERMSTERMS
Indicates a term or definition used in this manual.
u
Terms and Abbreviations
TERMSTERMS
• Drive: Yaskawa V1000 Series Drive
• PM motor: Synchronous motor (an abbreviation for IPM motor or SPM motor)
• IPM motor: SSR1 Series
• SPM motor: Pico motor (SMRA Series)
i.1 Preface
10
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
