A.2 Single/Three-Phase 200 V Class Drive

Table A.2 Power Ratings

Item Specification

Three-Phase: CIMR-Vo2A

0001 0002 0004 0006 0010 0012 0020

Single-Phase: CIMR-VoBA <1>

0001 0002 0003 0006 0010 0012 0018

Maximum Motor Size Allowed (HP) <2>

ND Rating 0.13 0.25 0.5/0.75 1.0/1.5 2.0/3.0 3.0 5.5 <8>

HD Rating 0.13 0.25 0.5/0.75 0.75/1.0 1.5/2.0 3.0 3.7

Input Input Current (A) <3>

Three

Phase

ND Rating 1.1 1.9 3.9 7.3 10.8 13.9 24.0

HD Rating 0.7 1.5 2.9 5.8 7.5 11.0 18.9

Single

Phase

ND Rating 2.0 3.6 7.3 13.8 20.2 24.0 –

HD Rating 1.4 2.8 5.5 11.0 14.1 20.6 35.0

Output

Rated Output Capacity (kVA) <4>

ND Rating 0.5 0.7 1.3 2.3 3.7 4.6 7.5

HD Rating 0.3 0.6 1.1 1.9 3.0 4.2 6.7

Output Current (A)

ND Rating <5> 1.2 1.9 3.5 (3.3) 6.0 9.6 12.0 19.6

HD Rating 0.8 <6> 1.6 <6> 3.0 <6> 5.0 <6> 8. <7> 11.0 <7> 17.5 <7>

Overload Tolerance

ND Rating: 120% of rated output current for 1 minute

HD Rating: 150% of rated output current for 1 minute

(Derating may be required for applications that start and stop frequently)

Carrier Frequency 2 kHz (user-set, 2 to 15 kHz)

Max Output Voltage (V)

Three-phase power: Three-phase 200 to 240 V

Single-phase power: Three-phase 200 to 240 V

(both proportional to input voltage)

Max Output Frequency (Hz) 400 Hz (user-adjustable)

Power Supply

Rated Voltage

Rated Frequency

Three-phase power: Three-phase 200 to 240 V 50/60 Hz

Single-phase power: 200 to 240 V 50/60 Hz

Allowable Voltage Fluctuation -15 to 10%

Allowable Frequency Fluctuation ±5%

Harmonic Countermeasures DC Reactor Optional

Heat Generation (W)

ThreePhas

ND Rating 13.0 17.1 29.4 44.7 77.5 91.7 145.0

HD Rating 11.6 16.7 27.6 43.3 78.6 100.7 153.8

SinglePha

ND Rating 13.5 17.3 29.0 49.5 81.5 98.4 –

HD Rating 11.7 16.8 27.6 50.5 80.7 104.8 161.9

<1> Drives with single-phase power supply inputs output three-phase power, and cannot run a single-phase motor.

<2> The motor capacity (HP) refers to a NEC rated 4-pole motor. The rated output current of the drive output amps should be equal to or greater than the motor rated current.

<3> Input current rating varies depending on the power supply transformer, input reactor, wiring connections, and power supply impedance.

<4> Rated motor capacity is calculated with a rated output voltage of 230 V.

<5> Carrier frequency is set to 2 kHz. Current derating is required in order to raise the carrier frequency.

<6> Carrier frequency is set to 10 kHz. Current derating is required in order to raise the carrier frequency.

<7> Carrier frequency is set to 8 kHz. Current derating is required in order to raise the carrier frequency.

<8>

CIMR-VoBA0020 only. CIMR-VoBA0018 is available with a Heavy Duty rating only.

Table A.3 Power Ratings Continued

Item Specification

Three-Phase: CIMR-Vo2A

0030 0040 0056 0069

Single-Phase: CIMR-VoBA <1>

- - - -

Maximum Motor Size Allowed (HP) <2>

ND Rating 10.1 14.8 20.1 24.8

HD Rating 7.4 10.1 14.8 20.1

Input Input Current (A) <3>

Three-Phase

ND Rating 34.7 50.9 69.4 85.6

HD Rating 26.0 35.4 51.9 70.8

Single-Phase

ND Rating - - - -

HD Rating - - - -

Output

Rated Output Capacity (kVA) <4>

ND Rating 11.4 15.2 21.3 26.3

HD Rating 9.5 12.6 17.9 22.9

Output Current (A)

ND Rating <5> 30.0 40.0 56.0 69.0

HD Rating 25.0 <7> 33.0 <7> 47. <7> 60.0 <7>

Overload Tolerance

ND Rating: 120% of rated output current for 1 minute

HD Rating: 150% of rated output current for 1 minute

(Derating may be required for applications that start and

stop frequently)
