YASKAWA V1000 Series Technical Manual

quick
flashing
flashing
ON ON
ON
ON ON
ON
1 s
Figure 4.1 RUN LED Status and Meaning
drive output frequency
during stop
frequency setting
OFF
/
ON
Flashing
OFFON
RUN LED
STOP STOP
RUN
0 Hz
6 Hz
RUN
Figure 4.2 RUN LED and Drive Operation
u
Menu Structure for Digital LED Operator
XXXX
XX
XX
XX
XX
XX
XX
XX
XX
XX
XX
XX
*
XX
XX
X
Turn the power on
Forward Selection
Reverse Selection
Output Frequency
Output Current
Output Voltage
Monitor Display
Verify Menu
Set Up Mode
Parameter Setting Mode
Auto-Tuning
DRV light is on.
*Pressing RUN will start the motor.
DRV light is off.
*Drive cannot operate the motor.
Description of Key Operations
:
:
:
:
Note: “XX” characters are shown in this manual.
The drive will display the actual setting values.
Figure 4.3 Digital LED Operator Screen Structure
* “rEu” can be selected while LOCAL is set.
4.2 Using the Digital LED Operator
60
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
