YASKAWA V1000 Series Technical Manual

5.6 F: Option Settings
u
F1: Settings for Simple PG with V/f Control
Although a pulse generator encoder (PG) is not available for the drive, it is equipped with a Pulse Train Input that can be used to improve speed control
accuracy. To take advantage of this feature, first set the drive for V/f Control (A1-02 = 0) and then set terminal RP for Simple PG in V/f (H6-01 = 3). For
applications operating more than one motor from a single drive, please note that this function is only available for motor 1.
n
F1-02: Operation Selection at PG Open Circuit (PGo)
Sets the stopping method when a PG open circuit fault (PGo) occurs. For a list of stopping methods, see
Refer to Stopping Methods for PGo, oS, dEv
Detection on page 155.
No. Parameter Name Setting Range Default
F1-02 Operation Selection at PG Open Circuit (PGO) 0 to 3 1
NOTICE: Setting = 3: Alarm only. This setting offers limited protection to the motor and machinery. Take proper precautions when selecting this setting.
n
F1-03: Operation Selection at Overspeed
Sets the stopping method when an overspeed (oS) fault occurs.
No. Parameter Name Setting Range Default
F1-03 Operation Selection at Overspeed (for Simple PG V/f) 0 to 3 1
NOTICE: Setting = 3: Alarm only. This setting offers limited protection to the motor and machinery. Take proper precautions when selecting this setting.
n
F1-04: Operation Selection at Deviation
Sets the stopping method when a speed deviation (dEv) fault occurs.
No. Parameter Name Setting Range Default
F1-04 Operation Selection at Deviation (for Simple PG V/f Control) 0 to 3 3
Note: The drive is set to continue operating when dEv is detected (F1-04 = 3).
Table 5.14 Stopping Methods for PGo, oS, dEv Detection
Setting Description
0 Ramp to Stop (uses the decleration time set to C1-02)
1 Coast to Stop
2 Fast Stop (uses the Fast Stop time set to C1-09)
3 Alarm only
n
F1-08: Overspeed Detection Level
n
F1-09: Overspeed Detection Delay Time
F1-08 is set as a percentage of the maximum output frequency and determines the level at which oS is detected.
F1-09 determines the time it takes for oS to be detected after the motor speed exceeds the detection level set to F1-08.
No. Parameter Name Setting Range Default
F1-08 Overspeed Detection Level 0 to 120 115%
F1-09 Overspeed Detection Delay Time 0.0 to 2.0 1.0
n
F1-10: Excessive Speed Deviation Detection Level
n
F1-11: Excessive Speed Deviation Detection Delay Time
Configures the speed deviation fault (dEv) detection. dEv fault will occur if the speed deviation is greater than the F1-10 setting for a time longer than
F1-11. F1-10 is set as a percentage of the maximum output frequency (E1-04). Speed deviation is the difference between actual motor speed and the
frequency reference command.
No. Parameter Name Setting Range Default
F1-10 Excessive Speed Deviation Detection Level 0 to 50 10%
F1-11 Excessive Speed Deviation Detection Delay Time 0.0 to 10.0 0.5 s
n
F1-14: PG Open-Circuit Detection Time
Sets the time required to detect PGo.
No. Parameter Name Setting Range Default
F1-14 PG Open-Circuit Detection Time 0.0 to 10.0 2.0 s
5.6 F: Option Settings
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
155
5
Parameter Details

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
