YASKAWA V1000 Series

No. Name Description Range Def.
Control
Mode
Addr. Hex Pg.
V/f
OL
V
PM
r1-17 DWEZ Connection Parameter 9 (upper) Parameter 9 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 1850 —
r1-18 DWEZ Connection Parameter 9 (lower) Parameter 9 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 1851 —
r1-19 DWEZ Connection Parameter 10 (upper) Parameter 10 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 1852 —
r1-20 DWEZ Connection Parameter 10 (lower) Parameter 10 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 1853 —
r1-21 DWEZ Connection Parameter 11 (upper) Parameter 11 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 1854 —
r1-22 DWEZ Connection Parameter 11 (lower) Parameter 11 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 1855 —
r1-23 DWEZ Connection Parameter 12 (upper) Parameter 12 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 1856 —
r1-24 DWEZ Connection Parameter 12 (lower) Parameter 12 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 1857 —
r1-25 DWEZ Connection Parameter 13 (upper) Parameter 13 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 1858 —
r1-26 DWEZ Connection Parameter 13 (lower) Parameter 13 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 1859 —
r1-27 DWEZ Connection Parameter 14 (upper) Parameter 14 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 185A —
r1-28 DWEZ Connection Parameter 14 (lower) Parameter 14 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 185B —
r1-29 DWEZ Connection Parameter 15 (upper) Parameter 15 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 185C —
r1-30 DWEZ Connection Parameter 15 (lower) Parameter 15 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 185D —
r1-31 DWEZ Connection Parameter 16 (upper) Parameter 16 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 185E —
r1-32 DWEZ Connection Parameter 16 (lower) Parameter 16 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 185F —
r1-33 DWEZ Connection Parameter 17 (upper) Parameter 17 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 1860 —
r1-34 DWEZ Connection Parameter 17 (lower) Parameter 17 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 1861 —
r1-35 DWEZ Connection Parameter 18 (upper) Parameter 18 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 1862 —
r1-36 DWEZ Connection Parameter 18 (lower) Parameter 18 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 1863 —
r1-37 DWEZ Connection Parameter 19 (upper) Parameter 19 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 1864 —
r1-38 DWEZ Connection Parameter 19 (lower) Parameter 19 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 1865 —
r1-39 DWEZ Connection Parameter 20 (upper) Parameter 20 for connecting DWEZ (upper). 0000 to FFFF(H) 0 A A A 1866 —
r1-40 DWEZ Connection Parameter 20 (lower) Parameter 20 for connecting DWEZ (lower). 0000 to FFFF(H) 0 A A A 1867 —
u
T: Motor Tuning
Enter data into the following parameters to tune the motor and drive for optimal performance
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
PM
T1-00 Motor Selection 1/2
Selects which set of motor parameters are used and set during Auto-Tuning. If Motor
2 selection (H1-oo = 16) is not selected, this parameter will not be displayed.
1: 1st Motor - E1 to E2
2: 2nd Motor - E3 to E4
(this selection is not displayed if motor 2 has not been selected)
1, 2 1 A A − 700 —
T1-01
Auto-Tuning Mode
Selection
Selects the Auto-Tuning mode.
0: Rotational Auto-Tuning
2: Stationary Auto-Tuning, Terminal resistance only,
3: Rotational Auto-Tuning for V/f control (necessary for Energy Savings and Speed
Estimation type speed search)
0, 2, 3 <54>
2 or 3 in V/f
0 or 2 in
OLV2 for
Motor 2
A A − 701 —
T1-02 Motor Rated Power
Sets the motor rated power in kilowatts (kW).
Note: If motor power is given in horsepower, power in kW can be calculated using the
following formula: kW = HP x 0.746.
0.00 to 650.00 0.40 kW A A − 702 —
T1-03 <24>
Motor Rated Voltage Sets the motor rated voltage in volts (V). 0.0 to 255.5 200.0 V A A − 703 —
T1-04 Motor Rated Current Sets the motor rated current in amperes (A).
10 to 200% of
drive rated
current
<12> A A − 704 —
T1-05 Motor Base Frequency Sets the base frequency of the motor in Hertz (Hz). 0.0 to 400.0 60.0 Hz A A − 705 —
T1-06 Number of Motor Poles Sets the number of motor poles. 2 to 48 4 A A − 706 —
T1-07 Motor Base Speed Sets the base speed of the motor in revolutions per minute r/min (RPM). 0 to 24000 1750 r/min A A − 707 —
T1-11 Motor Iron Loss
Provides the iron loss for determining the Energy Saving coefficient.
The value set to E2-10 (motor iron loss) when the power is cycled. If T1-02 is changed,
an initial value valid for the selected capacity will be shown.
0 to 65535
14W A − − 70B —
These values differ depending on the motor code
value and motor parameter settings.
<12> Default setting value is dependent on parameter o2-04, Drive/kVA Selection.
<24> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
<54> The available tuning methods depend on control mode. Select values 2 or 3 in V/f control, 0 or 2 in OLV control, and 2 for Motor 2 control.
u
U: Monitors
Monitor parameters allow the user to view drive status, fault information, and other information about drive operation.
No. Name Description Analog Output Level Unit
Control Mode
Addr. Hex
V/f OLV PM
U1: Operation Status Monitors
Use U1 monitors to display the operation status of the drive.
U1-01
Frequency Reference Monitors the frequency 10 V: Max frequency 0.01Hz A A A 40
U1-02 Output Frequency Displays the output voltage. Display units are determined by o1-03. 10 V: Max frequency
0.01Hz
<27>
A A A 41
U1-03 Output Current Displays the output current. 10 V: Drive rated current 0.01A A A A 42
B.2 Parameter Table
