F6 and F7: Serial Communications Option Card Settings
n
F6-01: Communications Error Option Selection
Parameter Overview
No. Name Description Range Default
F6-01 Communications Error Operation Selection
Selects the operation after a communications error occurred.
0: Ramp to stop using current accel/decel time
1: Coast to stop
2: Fast Stop using C1-09
3: Alarm only
0 to 3 1
n
F6-02: External Fault from Comm. Option Selection
Parameter Overview
No. Name Description Range Default
F6-02 External Fault from Comm. Option Selection
Sets when an external fault from a comm option is detected.
0: Always detected
1: Detection during Run only
0 or 1 0
n
F6-03: External Fault from Comm. Option Operation Selection
Parameter Overview
No. Name Description Range Default
F6-03 External Fault from Comm. Option Operation Selection
Selects the operation after an external fault set by a communications option
(EF0).
0: Ramp to stop using current accel/decel time
1: Coast to stop
2: Fast Stop using C1-09
3: Alarm only
0 to 3 1
n
F6-04: Trace Sampling Rate
Parameter Overview
No. Name Description Range Default
F6-04 Trace Sampling Rate - 0.0 to 5.0 2.0 s
n
F6-10: CC-Link Node Address
Parameter Overview
No. Name Description Range Default
F6-10 CC-Link Node Address Sets the node address if a CC-Link option card is installed 0 to 63 0
n
F6-11: CC-Link Communication Speed
Parameter Overview
No. Name Description Range Default
F6-11 CC-Link Communication Speed
0: 156 Kbps
1: 625 Kbps
2: 2.5 Mbps
3: 5 Mbps
4: 10 Mbps
0 to 4 0
n
F6-14: BUS Error Auto Reset
Parameter Overview
No. Name Description Range Default
F6-14 BUS Error Auto Reset Selects if a BUS fault can be automatically reset. 0 or 1 0
n
F6-20: DeviceNet MAC Address
Parameter Overview
No. Name Description Range Default
F6-20 DeviceNet MAC Address Selects the drives MAC address for DeviceNet 0 to 63 0
n
F6-21: DeviceNet Communication Speed
Parameter Overview
No. Name Description Range Default
F6-21 DeviceNet Communication Speed
0: 125 kbps
1: 250 kbps
2: 500 kbps
3: Detect automatically
0 to 3 3
