YASKAWA V1000 Series Technical Manual

4.4 Start-up Flowcharts
The flowcharts in this section summarize basic steps required to start-up the drive. Use the flowcharts to determine the most appropriate start-up method
for a given application. The charts are intended as a quick reference to help familiarize the user with start-up procedures.
Refer to Basic Drive Setup
Adjustments on page 75 and perform all checks to ensure a proper drive start-up.
Flowchart Subchart Objective Page
A Basic start-up procedure and motor tuning. 67
A-1 Simple motor set-up with Energy Savings or Speed Search using V/f mode. 67
A-2 High-performance operation using Open Loop Vector (OLV) motor control. 68
A-3 Operation with Permanent Magnet (PM) motors. 68
- Set-up of drive using application specific selections. Refer to Application Presets on page 70 -
4.4 Start-up Flowcharts
66
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
