YASKAWA V1000 Series

Table 4.4 lists parameters available in the Setup Group.
Note: This manual also explains other parameters not visible in the Setup Group (A1-06 = 0). Use the “Par” menu in the Programming mode to access parameters not listed in the
Setup Group. The Setup Group parameters are shown in Table 4.4
Note: Display parameters depend on A1-06. Refer to Application Presets on page 70.
Table 4.4 Setup Group Parameters
Parameter Name
A1-02 Control Method Selection
b1-01 Frequency Reference Selection 1
b1-02 Run Command Selection 1
b1-03 Stop Method Selection
C1-01 Acceleration Time 1
C1-02 Deceleration Time 1
C6-01 Duty Selection
C6-02 Carrier Frequency Selection
d1-01 Frequency Reference 1
d1-02 Frequency Reference 2
d1-03 Frequency Reference 3
d1-04 Frequency Reference 4
d1-17 Jog Frequency Reference
Parameter Name
E1-01 Input Voltage Reference
E1-03 V/f Pattern Selection
E1-04 Maximum Output Frequency (FMAX)
E1-05 Maximum Voltage (VMAX)
E1-06 Base Frequency (FA)
E1-09 Minimum Output Frequency (FMIN)
E1-13 Base Voltage (VBASE)
E2-01 Motor Rated Current
E2-04 Number of Motor Poles
E2-11 Motor Rate Capacity
H4-02 Terminal FM Gain Setting
L1-01 Motor Protection Function Selection
L3-04 Stall Prevention Selection during Deceleration
4.3 The Drive and Programming Modes
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
65
4
Start-Up Programming & Operation
