4.5 Application Presets
u
Application Preset Function (APPL)
This drive incorporates a function to set the parameters automatically for the applications that are frequently used. Using this Application Preset Function
can set or run the drive easily.
1: Water supply pump
2: Conveyor 3: Air supply/exhaust fan
4: AHU (HVAC) fan 5: Compressor 6: Hoist (elevator)
7: Cranes (traverse, traveling)
Note: For the details of these functions, Refer to Application Presets on page 70.
Pump
Conveyor Fan
u
Application Presets: A1-06
The drive features application presets to facilitate the set up of commonly used applications such as a water supply pump, conveyor, exhaust fan, HVAC
fan, compressor, hoist, and crane. Selecting one of these presets automatically sets the required parameters to the optimum values and changes the
appropriate I/O terminal settings for that specific application.
Verify all I/O signals and external sequences before operating the motor.
Refer to Hoist Application Preset Specifics on page 73 when selecting a hoist application.
Users are able to make further adjustments to these settings using the Setup Mode.
No. Parameter Name Setting Range Default
A1-06 Application Presets
0: General-purpose (A2 parameters are not affected)
1: Water supply pump
2: Conveyor
3: Exhaust fan
4: HVAC fan
5: Air compressor
6: Hoist
7: Crane (hoist, traverse)
0 <1>
<1> All general-purpose parameters are accessible when A1-06 = 0.
WARNING! Confirm the drive I/O signals and external sequence before starting test run. Setting parameter A1-06 may change the I/O terminal function automatically from the
factory setting. Failure to comply may result in death or serious injury.
Perform a 2-wire or 3-wire initialization (A1-03 = 2220 or 3330) on the drive before selecting one of the application presets or before switching between
application presets. The initialization process should reset drive parameters before using an application preset.
Save user-edited parameters to a list by setting o2-03 to “1”. This allows for more immediate access a specific list of relevant parameters and saves time
scrolling through the parameter menu items.
Set the parameter access level for Preferred Parameters (A1-01 = “1”) to display only the setup parameters.
The parameters listed in the table below are unaffected by drive initialization:
No. Parameter Name
A1-02 <1> Control Method Selection
C6-01 Duty Selection
E1-03 V/f Pattern Selection
E5-01 Motor Code Selection (for PM motors)
o2-04 Drive/kVA Selection
<1> The control method set to A1-02 is unaffected when performing a 2-wire or 3-wire initialization, but it automatically changes according to the value set to parameter A1-06.
n
Related Parameters
No. Parameter Name Setting Range Default
A1-01 Access Level Selection
0: Operation only
1: User Parameters (access to a set of parameters selected by the user)
2: Advanced Access Level
2 <1>
A1-03 Initialize Parameters
0: No Initialize
1110: User Initialize (The user must first set user parameter values and then store them using parameter o2-03)
2220: 2-Wire Initialization
3330: 3-Wire Initialization
4440: DriveWorksEZ Initialization
5550: OPE04 Error Reset
0
A2-02
to
A2-32
User Parameters,
2 to 32
b1-01 to o2-08 <1>
A2-33 User Parameter Automatic Selection
0: Parameters A2-01 through A2-32 are reserved for the user to create a list of User Parameters.
1: Save history of recently viewed parameters. Recently edited parameters will be saved to A2-17 through A2-32
for quick access.
1 <2>
4.5 Application Presets
70
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
