YASKAWA V1000 Series

A.5 Drive Watts Loss Data
Table A.6 Watts Loss 200 V Class Single-Phase Models
Drive Duty Fc (kHz)
Model Number
CIMR-Vo
Rated Amps (A) Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
HD
8
BA0001 0.8 28.7 15.5 44.2
BA0002 1.6 38.8 21.9 60.7
BA0003 3.0 52.0 29.5 81.5
BA0006 5.0 80.6 43.9 124.5
BA0010 8.0 4.7 12.5 17.2
BA0012 11.0 7.2 13.7 20.9
BA0020 17.5 14.0 18.6 32.6
2
BA0001 0.8 3.0 7.1 10.1
BA0002 1.6 6.0 8.4 14.4
BA0003 3.0 12.6 10.6 23.2
BA0006 5.0 28.7 15.5 44.2
BA0010 8.0 38.8 21.9 60.7
BA0012 11.0 52.0 29.5 81.5
BA0020 17.5 80.6 43.9 124.5
ND 2
BA0001 1.2 4.7 12.5 17.2
BA0002 1.9 7.2 13.7 20.9
BA0003 3.2 14.0 18.6 32.6
BA0006 6.0 35.6 25.6 61.2
BA0010 9.6 48.6 34.5 83.1
BA0012 12.0 57.9 42.6 100.5
Table A.7 Watts Loss 200 V Class Three-Phase Models
Drive Duty Fc (kHz)
Model Number
CIMR-Vo
Rated Amps (A) Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
HD
8
2A0001 0.8 4.3 7.3 11.6
2A0002 1.6 7.9 8.8 16.7
2A0004 3.0 16.1 11.6 27.7
2A0006 5.0 27.4 15.9 43.3
2A0010 8.0 54.8 23.8 78.6
2A0012 11.0 70.7 29.9 100.6
2A0020 17.5 110.5 43.3 153.8
2
2A0001 0.8 3.0 7.0 10.0
2A0002 1.6 6.0 8.3 14.3
2A0004 3.0 12.6 10.6 23.2
2A0006 5.0 21.1 14.3 35.4
2A0010 8.0 38.8 19.8 58.6
2A0012 11.0 52.0 25.3 77.3
2A0020 17.5 80.6 35.8 116.4
ND 2
2A0001 1.2 4.7 11.9 16.6
2A0002 1.9 7.2 13.5 20.7
2A0004 3.5 15.1 17.7 32.8
2A0006 6.0 26.2 21.4 47.6
2A0010 9.6 48.6 30.5 79.1
2A0012 12.0 57.9 35.9 93.8
2A0020 19.6 93.3 53.0 146.3
Table A.8 Watts Loss 400 V Class Three-Phase Models
Drive Duty Fc (kHz)
Model Number
CIMR-Vo
Rated Amps (A) Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
HD
8
4A0001 1.2 19.2 11.5 30.7
4A0002 1.8 28.9 14.8 43.7
4A0004 3.4 42.3 17.9 60.2
4A0005 4.8 70.7 26.2 96.9
4A0007 5.5 81.0 30.7 111.7
4A0009 7.2 84.6 32.9 117.5
4A0011 9.2 107.2 41.5 148.7
2
4A0001 1.2 8.2 8.6 16.8
4A0002 1.8 13.0 10.9 23.9
4A0004 3.4 21.3 12.6 33.9
4A0005 4.8 32.8 16.8 49.6
4A0007 5.5 38.2 20.0 58.2
4A0009 7.2 44.3 22.8 67.1
4A0011 9.2 57.6 29.1 86.7
A.5 Drive Watts Loss Data
288
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
