YASKAWA V1000 Series

Drive Duty Fc (kHz)
Model Number
CIMR-Vo
Rated Amps (A) Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
ND 2
4A0001 1.2 8.2 14.4 22.6
4A0002 2.1 15.5 18.4 33.9
4A0004 4.1 26.4 21.2 47.6
4A0005 5.4 37.5 25.7 63.2
4A0007 6.9 49.7 32.4 82.1
4A0009 8.8 55.7 36.0 91.7
4A0011 11.1 71.9 51.7 123.6
A.5 Drive Watts Loss Data
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
289
A
Specifications
