YASKAWA V1000 Series

No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
PM
n3-23 Overexcitation Operation Selection
0: Disabled
1: Enabled only when rotating forward
2: Enabled only when in reverse
0 to 2 0 A A − —
n6: Tuning of Resistance between Motor Lines
Use n6 parameters to adjust the motor line-to-line resistance.
n6-01
Line-to-Line Motor Resistance Online
Tuning
Tunes the line-to-line motor resistance continuously during operation.
0: Disabled
1: Enabled
0, 1 1 − A − 570 —
n8: Permanent Magnet (PM) Motor Control
Use n8 parameters to control the PM motor control.
n8-45
Speed Feedback Detection Control
Gain
Sets the gain for internal speed feedback detection control. This parameter does
not typically require adjustment.
Increase this setting if hunting occurs.
Decrease to lower the response.
0.0 to 10.0 0.8 − − A 538 —
n8-47
Pull-In Current Compensation Time
Constant
Sets the time constant to make the pull-in current and actual current value agree.
Decrease the value if the motor begins to oscillate.
Increase the value if it takes too long for the current reference to equal the output
current.
0.0 to 100.0 s 5.0 s − − A 53A —
n8-48 Pull-In Current
Defines the amount of current provided to the motor during no load operation at
a constant speed.
Set as a percentage of the motor rated current. Increase this setting when hunting
occurs while running at a constant speed.
20 to 200% 30% − − A 53B —
n8-49 Load Current Sets the amount of d-axis current when using Energy Saving control.
-200.0 to
0.0%
0% − − A 53C —
n8-51 Acceleration Pull-In Current
Sets the pull-in current during acceleration as a percentage of the motor rated
current (E5-03). Set to a high value when more starting torque is needed.
0 to 200% 50% − − A 53E —
n8-54
Voltage Error compensation time
constant
Sets the time constant for voltage error compensation. Adjust the value when
• hunting occurs at low speed.
• hunting occurs with sudden load changes. Increase in steps of 0.1 or disable
the compensation by setting n8-45 to 0.
• oscillations occur ar start. Increase the value in steps of 0.1.
0.00 to 10.00 s 1.00s − − A 56D —
n8-55 Load Inertia
Sets the ratio between motor and machine inertia.
0: less than 1:10.
1: between 1:10 to 1:30.
2: between 1:30 to 1:50.
3: higher than 1:50.
0 to 3 0 − − A 56E —
n8-62 <24> Output voltage limit
Sets the limit for the output voltage.
Adjustment is normally needed only if the input voltage is below the n8-62 set
value. In this case set n8-62 to the input voltage.
0.0 to 230.0 200 Vac - - A 57D —
<12> Default setting value is dependent on parameter o2-04, Drive/kVA Selection.
<24> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
u
o: Operator Related Parameters
o parameters are used to set up the LED digital operator displays.
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
PM
o1: Display Settings
Use o1 parameters to configure the digital operator display.
o1-01 <22> Drive Mode Unit Monitor Selection
Selects which monitor will be displayed in the operation menu upon power-up
when o1-02 = 5. The monitor parameter number is entered into the spaces
provided: Uo-oo. For example, set “403” to display monitor parameter U4-03.
104 to 621 106 A A A 500 —
Set to U1-06 as a default (Output Voltage Reference). —
o1-02 <22>
User Monitor Selection After Power
Up
Selects the monitor to display upon power-up.
1: Frequency Reference (U1-01)
2: Forward/Reverse
3: Output Frequency (U1-02)
4: Output Current (U1-03)
5: User Monitor (set by o1-01)
1 to 5 1 A A A 501 —
o1-03 Digital Operator Display Selection
Sets the units to display the frequency reference and output frequency.
0: Hz
1:% (100% = E1-04)
2: r/min (enter the number of motor poles into E2-04/E4-04/E5-04)
3: User defined by parameters o1-10 and o1-11
0 to 3 0 A A A 502 —
o1-10
Frequency Reference Setting and User-
Set Display
These settings define the display values when o1-03 is set to 3.
o1-10 sets display values when operating at the maximum output frequency.
o1-11 sets the position of the decimal positions.
□□□□□□
o1-10: Sets the first five
digits of the value,
disregarding the
decimal point.
o1-11: Sets the number
of digits past the
decimal point
1 to 60000 <11> A A A 520 —
o1-11
Frequency Reference Setting / Decimal
Display
0 to 3 <11> A A A 521 —
B.2 Parameter Table
316
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
