YASKAWA V1000 Series Technical Manual

1.3 Drive Models and Enclosure Types
The following table describes drive enclosures and models.
Table 1.1 Drive Models and Enclosure Types
Voltage Class
Enclosure Type
IP20/Open-Chassis
CIMR-Vo
IP20/ NEMA Type 1
CIMR-Vo
Single-Phase
200 V Class
BA0001B BA0001F
BA0002B BA0002F
BA0003B BA0003F
BA0006B BA0006F
BA0010B BA0010F
BA0012B BA0012F
BA0018B BA0018F
Three-Phase
200 V Class
2A0001B 2A0001F
2A0002B 2A0002F
2A0004B 2A0004F
2A0006B 2A0006F
2A0010B 2A0010F
2A0012B 2A0012F
2A0020B 2A0020F
2A0030B 2A0030F
2A0040B 2A0040F
2A0056B 2A0056F
2A0069B 2A0069F
Three-Phase
200 V Class
2A0001B 2A0001F
2A0002B 2A0002F
2A0004B 2A0004F
2A0006B 2A0006F
2A0010B 2A0010F
2A0012B 2A0012F
2A0020B 2A0020F
2A0030B 2A0030F
2A0040B 2A0040F
2A0056B 2A0056F
2A0069B 2A0069F
Three-Phase
200 V Class
2A0001B 2A0001F
2A0002B 2A0002F
2A0004B 2A0004F
2A0006B 2A0006F
2A0008B 2A0008F
2A0010B 2A0010F
2A0012B 2A0012F
2A0018B 2A0018F
2A0020B 2A0020F
2A0030B 2A0030F
2A0040B 2A0040F
2A0056B 2A0056F
2A0069B 2A0069F
Three-Phase
400 V Class
4A0001B 4A0001F
4A0002B 4A0002F
4A0004B 4A0004F
4A0005B 4A0005F
4A0007B 4A0007F
4A0009B 4A0009F
4A0011B 4A0011F
4A0018B 4A0018F
4A0023B 4A0023F
4A0031B 4A0031F
4A0038B 4A0038F
TERMSTERMS
• Two types of enclosures are offered for V1000 drives.
• IP20/Open-Chassis models are often placed inside a large enclosure panel where the front of the drive is covered to prevent someone from accidentally touching charged
components.
• IP20/NEMA Type 1 models mount to an indoor wall and not inside a large enclosure panel.
1.3 Drive Models and Enclosure Types
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
19
1
Receiving

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
