D.2 European Standards
Figure D.1 CE Mark
The CE mark indicates compliance with European safety and environmental regulations and is required for engaging in business and commerce in Europe.
European standards include the Machinery Directive for machine manufacturers, the Low Voltage Directive for electronics manufacturers and the EMC
guidelines for controlling noise.
This drive displays the CE mark based on the EMC guidelines and the Low Voltage Directive.
• EMC Guidelines: Devices used in combination with this drive must also be CE certified and display the CE mark. When using drives displaying the
CE mark in combination with other devices, it is ultimately the responsibility of the user to ensure compliance with CE standards. After setting up the
device, verify that conditions meet European standards.
• Low Voltage Directive: 73/23/EEC, 93/68/EEC
u
CE Low Voltage Directive Compliance
This drive has been tested according to European standard EN50178, and it fully complies with the Low Voltage Directive.
To comply with the Low Voltage Directive, be sure to meet the following conditions when combining this drive with other devices:
n
Area of Use
Do not use drives in areas with pollution higher than severity 2 and overvoltage category 3 in accordance with IEC664.
n
Installing Fuses on the Input Side
Install recommended UL-approved fuses at the main power input of the drive. Select fuses according to
Table D.1 .
Table D.1 Recommended Input Fuse Selection
Drive Model CIMR-Vo
Time Delay/
Class RK5 Fuses
600 Vac, 200 kAIR
Fuse Ampere Rating
Non-Time Delay/
Class T Fuses
600 Vac, 200 kAIR
200 V Class Single-Phase Drives
BA0001 TRS5R 5
Contact Yaskawa
BA0002 TRS10R 10
BA0003 TRS20R 20
BA0006 TRS35R 35
BA0010 TRS50R 50
BA0012 TRS60R 60
BA0018 Contact Yaskawa
200 V Class Three-Phase Drives
2A0001 TRS5R 5
2A0002 TRS5R 5
2A0004 TRS10R 10
2A0006 TRS15R 15
2A0010 TRS25R 25 Contact Yaskawa
2A0012 TRS35R 35
2A0020 TRS60R 60
2A0030
Not Available
70 A6T70
2A0040 100 A6T100
2A0056 150 A6T150
2A0069 200 A6T200
400 V Class Three-Phase Drives
4A0001 TRS2.5R 2.5
Contact Yaskawa
4A0002 TRS5R 5
4A0004 TRS10R 10
4A0005 TRS20R 20
4A0007 TRS20R 20
4A0009 TRS20R 20
4A0011 TRS30R 30
4A0018
Not Available
50 A6T50
4A0023 60 A6T60
4A0031 70 A6T70
4A0038 80 A6T80
n
Guarding Against Harmful Materials
When installing IP20/Open-Chassis drives, use an enclosure that prevents foreign material from entering the drive from above or below.
D.2 European Standards
348
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
