YASKAWA V1000 Series

No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
PM
C6-03 Carrier Frequency Upper Limit Open Loop Vector: C6-03 defines the fixed carrier frequency if C6-02 = F.
V/f control: C6-03 and C6-04 set upper and lower limits for the carrier
frequency.
carrier frequency
E1-04
max output
frequency
output frequency
× (C6-05) × K
output
frequency
C6-03
C6-04
The coefficient K depends on C6-03:
C6-03 ≥ 10.0 kHz: K = 3
10.0 kHz > C6-03 ≥ 5.0 kHz: K = 2
5.0 kHz > C6-03: K = 1
When C6-05 ≤ 6, C6-04 is disabled (makes the carrier frequency C6-03 value).
1.0 to 15.0 <8> A A A 225 —
C6-04 Carrier Frequency Lower Limit 0.4 to 15.0 <8> A - - 226 —
C6-05 Carrier Frequency Proportional Gain
Sets the relationship of output frequency to carrier frequency when C6-02 =
F.
00 to 99 <8> A - - 227 —
<1> Default setting value is dependent on parameter A1-02, Control Method Selection. The value shown is for A1-02 = 2-OLV control.
<2> Default setting value is dependent on parameter A1-02, Control Method Selection. The value shown is for A1-02 = 0-V/f Control.
<3> Default setting value is dependent on parameters o2-04, Drive/kVA Selection, A1-02, Control Method Selection and C6-01, Normal/Heavy Duty selection. 351.
<6> Setting range value is dependent on parameter C1-10, Accel/Decel Time Setting Units. When C1-10 = 0 (units of 0.01 seconds), the setting range becomes 0.00 to 600.00 seconds.
<8> Default setting value is dependent on parameter C6-02, Carrier Frequency Selection.
<22> Parameter can be changed during run.
<23> Parameter cannot be changed during run when parameter A1-02 = 5-PM OLV Control.
u
d: References
Reference parameters are used to set the various frequency reference values during operation.
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
PM
d1: Frequency Reference
Use d1 parameters to configure the drive frequency reference.
d1-01 <22>
Frequency Reference 1 Frequency reference
0.00 to 400.00
Hz <11>
<19>
0.00 Hz S S S 280 76
d1-02 <22>
Frequency Reference 2
Frequency reference when digital input "Multi-Step Speed Reference 1" (H1-oo
= 3) is on.
0.00 Hz S S S 281 76
d1-03 <22>
Frequency Reference 3
Frequency reference when digital input "Multi-Step Speed Reference 2” (H1-oo
= 4) is on.
0.00 Hz S S S 282 76
d1-04 <22>
Frequency Reference 4
Frequency reference when digital inputs "Multi-Step Speed Reference 1, 2" (H1-
oo = 3 and 4) are on.
0.00 Hz S S S 283 76
d1-05 <22>
Frequency Reference 5
Frequency reference when digital input "Multi-Step Speed Reference 3" (H1-oo
= 5) is on.
0.00 Hz A A A 284 —
d1-06 <22>
Frequency Reference 6
Frequency reference when digital inputs "Multi-Step Speed Reference 1, 3 " (H1-
oo = 3 and 5) are on.
0.00 Hz A A A 285 —
d1-07 <22>
Frequency Reference 7
Frequency reference when digital inputs "Multi-Step Speed Reference 2, 3" (H1-
oo = 4 and 5) are on.
0.00 Hz A A A 286 —
d1-08 <22>
Frequency Reference 8
Frequency reference when multi-function input "Multi-Step speed reference 1, 2,
3" (H1-oo = 3, 4, 5) are on.
0.00 Hz A A A 287 —
d1-09 <22>
Frequency Reference 9
Frequency reference when multi-function input "Multi-Step Speed Reference
4" (H1-oo = 32) is on.
0.00 Hz A A A 288 —
d1-10 <22>
Frequency Reference 10
Frequency reference when digital input "Multi-Step Speed Reference 1, 4" (H1-
oo = 3 and 32) are on.
0.00 Hz A A A 28B —
d1-11 <22>
Frequency Reference 11
Frequency reference when digital inputs "Multi-Step Speed Reference 2, 4" (H1-
oo = 4 and 32) are on.
0.00 Hz A A A 28C —
d1-13 <22>
Frequency Reference 13
Frequency reference when digital inputs "Multi-Step Speed Reference 3, 4" (H1-
oo = 5 and 32) are on.
0.00 Hz A A A 28E —
d1-14 <22>
Frequency Reference 14
Frequency reference when digital inputs "Multi-Step Speed Reference 1, 3, 4" (H1-
oo = 3, 5, 32) are on.
0.00 Hz A A A 28F —
d1-15 <22>
Frequency Reference 15
Frequency reference when digital inputs "Multi-Step Speed Reference 2, 3, 4" (H1-
oo = 4, 5, 32) are on.
0.00 Hz A A A 290 —
d1-16 <22>
Frequency Reference 16
Frequency reference when digital inputs "Multi-Step Speed Reference 1, 2, 3,
4" (H1-oo = 3, 4, 5, 32) are on.
0.00 Hz A A A 291 —
d1-17 <22>
Jog Frequency Reference
Frequency reference when digital inputs "Jog Frequency Reference", "Forward Jog"
or "Reverse Jog." are on. "Jog Frequency Reference" has priority over "Multi-Step
Speed Reference 1 to 16”.
6.00 Hz S S S 292 76
d2: Frequency Upper and Lower Limits
Use d2 parameters to configure the frequency reference limits.
d2-01 Frequency Reference Upper Limit
Sets the frequency reference upper limit as a percentage of maximum output
frequency (E1-04). Output speed is limited to this value even if the frequency
reference is higher. This limit applies to all frequency reference sources.
0.0 to 110.0 100.0% A A A 289 —
d2-02 Frequency Reference Lower Limit
Sets the frequency reference lower limit as a percentage of maximum output
frequency (E1-04). Output speed is limited to this value even if the frequency
reference is lower. This limit applies to all frequency reference sources.
0.0 to 110.0 0.0% A A A 28A —
B.2 Parameter Table
