D.3 UL Standards
The UL/cUL mark applies to products in the United States and Canada indicates that UL has performed product testing and evaluation and determined
that their stringent standards for product safety have been met. For a product to receive UL certification, all components inside that product must also
receive UL certification.
U
L
C
R
US
LISTED
Figure D.7 UL/cUL Mark
u
UL Standards Compliance
This drive is tested in accordance with UL standard UL508C and complies with UL requirements. The following conditions must be met to maintain
compliance when using this drive in combination with other equipment:
n
Installation Area
Do not install the drive to an area greater than pollution severity 2 (UL standard).
n
Main Circuit Terminal Wiring
Yaskawa recommends using UL-listed copper wires (rated at 75°C) and closed-loop connectors or CSA-certified ring connectors sized for the selected
wire gauge to maintain proper clearances when wiring the drive. Use the correct crimp tool to install connectors per manufacturer recommendation.
Table D.4 lists a suitable closed-loop connector manufactured by JST Corporation.
Table D.4 Closed-Loop Crimp Terminal Size (JIS C 2805) (same for 200 V and 400 V)
Wire Gauge
mm
2
(AWG)
Terminal
Screws
Crimp Terminal
Model Numbers
Tightening Torque
N m (lb to in.)
0.75 (18)
M3.5 R1.25-3.5 0.8 to 1.0 (7.1 to 8.9)
M4 R1.25-4 1.2 to 1.5 (10.6 to 13.3)
1.25 (16)
M3.5 R1.25-3.5 0.8 to 1.0 (7.1 to 8.9)
M4 R1.25-4 1.2 to 1.5 (10.6 to 13.3)
2 (14)
M3.5 R2-3.5 0.8 to 1.0 (7.1 to 8.9)
M4 R2-4 1.2 to 1.5 (10.6 to 13.3)
M5 R2-5 2.0 to 2.5 (17.7 to 22.1)
M6 R2-6 4.0 to 5.0 (35.4 to 44.3)
3.5/5.5 (12/10)
M4 R5.5-4 1.2 to 1.5 (10.6 to 13.3)
M5 R5.5-5 2.0 to 2.5 (17.7 to 22.1)
M6 R5.5-6 4.0 to 5.0 (35.4 to 44.3)
M8 R5.5-8 9.0 to 11.0 (79.7 to 97.4)
8 (8)
M4 R8-4 1.2 to 1.5 (10.6 to 13.3)
M5 R8-5 2.0 to 2.5 (17.7 to 22.1)
M6 R8-6 4.0 to 5.0 (35.4 to 44.3)
M8 R8-8 9.0 to 11.0 (79.7 to 97.4)
14 (6)
M4 R8-4 1.2 to 1.5 (10.6 to 13.3)
M5 R14-5 2.0 to 2.5 (17.7 to 22.1)
M6 R14-6 4.0 to 5.0 (35.4 to 44.3)
M8 R14-8 9.0 to 11.0 (79.7 to 97.4)
22 (4)
M6 R22-6 4.0 to 5.0 (35.4 to 44.3)
M8 R22-8 9.0 to 11.0 (79.7 to 97.4)
30/38 (3/2) M8 R38-8 9.0 to 11.0 (79.7 to 97.4)
Note:
Use the specified crimp terminals (Model 14-NK4) when using CIMR-Vo2A0030, Vo2A0040, Vo4A0023 with 14 mm
2
(6 AWG).
Note: Use crimp insulated terminals or insulated shrink tubing for wiring connections. Wires should have a continuous maximum allowable temperature of 75°C 600 Vac UL-
approved vinyl-sheathed insulation.
Table D.5 Recommended Input Fuse Selection
Drive Model CIMR-Vo
Time Delay/
Class RK5 Fuses
600 Vac, 200 kAIR
Fuse Ampere Rating
200 V Class Single-Phase Drives
BA0001 TRS5R 5
BA0002 TRS10R 10
BA0003 TRS20R 20
BA0006 TRS35R 35
BA0010 TRS50R 50
BA0012 TRS60R 60
BA0018 Contact Yaskawa
200 V Class Three-Phase Drives
2A0001 TRS5R 5
2A0002 TRS5R 5
2A0004 TRS10R 10
D.3 UL Standards
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
353
D
Standards Compliance
