YASKAWA V1000 Series Technical Manual

n
Three-Phase 200 V
Normal Duty Heavy Duty
No. Max. Motor Capacity kW Rated Output Current A No. Max. Motor Capacity kW Rated Output Current A
0001 0.2 1.2 0001 0.1 0.8
0002 0.4 1.9 0002 0.2 1.6
0004 0.75 3.5 0004 0.4 3
0006 1.1 6 0006 0.75 5
0010 2.2 9.6 0010 1.5 8
0012 3.0 12 0012 2.2 11
0020 5.5 19.6 0020 3.7 17.5
0030 7.5 30 0030 5.5 25
0040 11 40 0040 7.5 33
0056 15 56 0056 11 47
0069 18.5 69 0069 15 60
n
Three-Phase 400 V
Normal Duty Heavy Duty
No. Max. Motor Capacity kW Rated Output Current A No. Max. Motor Capacity kW Rated Output Current A
0001 0.4 1.2 0001 0.2 1.2
0002 0.75 2.1 0002 0.4 1.8
0003 1.5 4.1 0003 0.75 3.4
0004 2.2 5.4 0004 1.5 4.8
0005 3.0 6.9 0005 2.2 5.5
0007 3.7 8.8 0007 3.0 7.2
0011 5.5 11.1 0011 3.7 9.2
0018 7.5 17.5 0018 5.5 14.8
0023 11 23 0023 7.5 18
0031 15 31 0031 11 24
0038 18.5 38 0038 15 31
* Drives with these specifications do not guarantee complete protection for the specified environmental condition.
Note: Refer to Component Names on page 20 for differences regarding enclosure protection types and component descriptions.
1.2 Model Number and Nameplate Check
18
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
