YASKAWA V1000 Series

No. Parameter Name Setting Range Default
o2-03 User Parameter Default Value
0: No Change
1: Set Defaults - Saves current parameter settings as user initialization.
2: Clear All - Clears the currently saved user initialization.
0
<1> Default setting value is dependent on parameter A1-06, Application Selection
<2> Default setting value is dependent on parameter A1-06. This setting value is 0 when A1-06 = 0, and 1 when A1-06 does not = 0.
n
Application Presets
Below is a list of application presets and the values automatically assigned to the parameters as a result of each preset:
Table 4.5 Water Supply Pump Application: Parameters and Settings
No. Parameter Name Optimum Setting
A1-02 Control Method Selection 0: V/f control
b1-04 Reverse Operation Selection 1: Reverse prohibited
C1-01 Acceleration Time 1 1.0 s
C1-02 Deceleration Time 1 1.0 s
C6-01 Duty Rating 1: Normal Duty
E1-03 V/f Pattern Selection 0FH
E1-07 Mid Output Frequency (FB) 30.0
E1-08 Mid Output Frequency Voltage (VC) 50.0
L2-01 Momentary Power Loss Operation Selection 1: Enabled
L3-04 Stall Prevention Selection during Deceleration 1: Enabled
Table 4.6 Parameters Automatically Saved as Preferred (A2-01 to A2-16)
No. Parameter Name No. Parameter Name
b1-01 Frequency Reference Selection E1-08 Mid Output Frequency Voltage (VC)
b1-02 Run Command Selection E2-01 Motor Rated Current
b1-04 Reverse Operation Selection H1-05 Multi-Function Digital Input Terminal S5 Function Selection
C1-01 Acceleration Time 1 H1-06 Multi-Function Digital Input Terminal S6 Function Selection
C1-02 Deceleration Time 1 H1-07 Multi-Function Digital Input Terminal S7 Function Selection
E1-03 V/f Pattern Selection L5-01 Number of Auto Restart Attempts
E1-07 Mid Output Frequency (FB)
Table 4.7 Conveyor Application: Parameters and Settings
No. Parameter Name Optimum Setting
A1-02 Control Method Selection 0: V/f control
C1-01 Acceleration Time 1 3.0 s
C1-02 Deceleration Time 1 3.0 s
C6-01 Duty Rating 0: Heavy Duty
L3-04 Stall Prevention Selection during Deceleration 1: Enabled
Table 4.8 Parameters Automatically Saved as Preferred (A2-01 to A2-16)
No. Parameter Name No. Parameter Name
A1-02 Control Method Selection C1-02 Deceleration Time 1
b1-01 Frequency Reference Selection E2-01 Motor Rated Current
b1-02 Run Command Selection L3-04 Stall Prevention Selection during Deceleration
C1-01 Acceleration Time 1
Table 4.9 Exhaust Fan Application: Parameters and Settings
No. Parameter Name Optimum Setting
A1-02 Control Method Selection 0: V/f control
b1-04 Reverse Operation Selection 1: Reverse Prohibited
C6-01 Duty Selection 1: Normal Duty
E1-03 V/f Pattern Selection 0FH
E1-07 Mid Output Frequency (FB) 30
E1-08 Mid Output Frequency Voltage (VC) 50
L2-01 Momentary Power Loss Operation Selection 1: Enabled
L3-04 Stall Prevention Selection during Deceleration 1: Enabled
Table 4.10 Parameters Automatically Saved as Preferred (A2-01 to A2-16)
No. Parameter Name No. Parameter Name
b1-01 Frequency Reference Selection E1-07 Mid Output Frequency (FB)
b1-02 Run Command Selection E1-08 Mid Output Frequency Voltage (VC)
b1-04 Reverse Operation Selection E2-01 Motor Rated Current
b3-01 Speed Search Selection at Start H1-05 Multi-Function Digital Input Terminal S5 Function Selection
C1-01 Acceleration Time 1 H1-06 Multi-Function Digital Input Terminal S6 Function Selection
C1-02 Deceleration Time 1 H1-07 Multi-Function Digital Input Terminal S7 Function Selection
E1-03 V/f Pattern Selection L5-01 Number of Auto Restart Attempts
Table 4.11 HVAC Fan Application: Parameters and Settings
No. Parameter Name Optimum Setting
A1-02 Control Method Selection 0: V/f control
b1-04 Reverse Operation Selection 1: Reverse prohibited
C6-01 Duty Rating 1: Normal Duty
4.5 Application Presets
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
71
4
Start-Up Programming & Operation
