YASKAWA V1000 Series

No. Parameter Name Optimum Setting
C6-02 Carrier Frequency Selection 3: 8.0 kHz
H2-03 Terminals P2 Function Selection (open-collector) 39: Watt Hour Pulse Output
L2-01 Momentary Power Loss Operation Selection
2: CPU Power Active - Drive will restart if power returns prior to
control power supply shut down.
L8-03 Overheat Pre-Alarm Operation Selection 4: Derated operation
L8-38 Carrier Frequency Reduction 2: Carrier frequency derating across entire frequency range.
Table 4.12 Parameters Automatically Saved as Preferred (A2-01 to A2-16)
No. Parameter Name No. Parameter Name
b1-01 Frequency Reference Selection E1-03 V/f Pattern Selection
b1-02 Run Command Selection E1-04 Max Output Frequency (FMAX)
b1-04 Reverse Operation Selection E2-01 Motor Rated Current
C1-01 Acceleration Time 1 H3-11 Terminal A2 Gain Setting
C1-02 Deceleration Time 1 H3-12 Frequency Reference (Current) Terminal A2 Input Bias
C6-02 Carrier Frequency Selection L2-01 Momentary Power Loss Operation Selection
d2-01 Frequency Reference Upper Limit L8-03 Overheat Pre-Alarm Operation Selection
d2-02 Frequency Reference Lower Limit o4-12 kWH Monitor Initial Value Selection
Table 4.13 Compressor Application: Parameters and Settings
No. Parameter Name Optimum Setting
A1-02 Control Method Selection 0: V/f control
b1-04 Reverse Operation Selection 1: Reverse prohibited
C1-01 Acceleration Time 1 5.0 s
C1-02 Deceleration Time 1 5.0 s
C6-01 Duty Rating 0: Heavy Duty
E1-03 V/f Pattern Selection 0FH
L2-01 Momentary Power Loss Operation Selection 1: Enabled
L3-04 Stall Prevention Selection during Deceleration 1: Enabled
Table 4.14 Parameters Automatically Saved as Preferred (A2-01 to A2-16)
No. Parameter Name No. Parameter Name
b1-01 Frequency Reference Selection E1-03 V/f Pattern Selection
b1-02 Run Command Selection E1-07 Mid Output Frequency (FB)
b1-04 Reverse Operation Selection E1-08 Mid Output Frequency Voltage (VC)
C1-01 Acceleration Time 1 E2-01 Motor Rated Current
C1-02 Deceleration Time 1
Table 4.15 Crane Application (Hoist): Parameters and Settings
No. Parameter Name Optimum Setting
A1-02 Control Method Selection 2: Open Loop Vector Control
b1-01 Frequency Reference Selection 0: Operator
b6-01 Dwell Reference at Start 3.0 Hz
b6-02 Dwell Time at Start 0.3 s
C1-01 Acceleration Time 1 3.0 s
C1-02 Deceleration Time 1 3.0 s
C6-01 Duty Rating 0: Heavy Duty
C6-02 Carrier Frequency Selection 2: 5 kHz
d1-01 Frequency Reference 1 6.0 Hz
d1-02 Frequency Reference 2 30.0 Hz
d1-03 Frequency Reference 3 60.0 Hz
E1-03 V/f Pattern Selection 0FH
H2-02 Terminals P1 Function Selection (open-collector) 37: During frequency output
H2-03 Terminals P2 Function Selection (open-collector) 5: Frequency Detection 2 (FOUT)
L2-03 Momentary Power Loss Minimum Baseblock Time 0.3 s
L3-04 Momentary Power Loss Voltage Recovery Ramp Time 0: Disabled
L4-01 Speed Agreement Detection Level 2.0 Hz
L4-02 Speed Agreement Detection Width 0.0 Hz
L6-01 Torque Detection Selection 1 8: UL3 at RUN -Fault
L6-02 Torque Detection Level 1 5%
L6-03 Torque Detection Time 1 0.5 s
L8-05 Input Phase Loss Protection Selection 1: Enabled
L8-07 Output Phase Loss Protection 1: Enabled
L8-38 Carrier Frequency Reduction 0: Derated when operating at 6 Hz or less
L8-41 Current Alarm Selection 1: Enabled (alarm is output)
Note: A sequence to release the brake is needed when the multi-function output photocoupler P2-PC closes. Refer to Hoist Application Preset Specifics on page 73 for more
information.
Note: Perform Auto-Tuning after selecting the Hoist Application Preset.
Table 4.16 Parameters Automatically Saved as Preferred (A2-01 to A2-16)
No. Parameter Name No. Parameter Name
A1-02 Control Method Selection d1-02 Frequency Reference 2
b1-01 Frequency Reference Selection d1-03 Frequency Reference 3
b6-01 Dwell Reference at Start E1-08 Mid Output Frequency Voltage (VC)
4.5 Application Presets
