No. Parameter Name Setting Range Default
E5-03 Motor Rated Current (PM OLV) 10 to 200% of drive rated current Determined by E5-01
Note: The default value is determined by the motor code set to E5-01. Setting units are determined by drive capacity. 7.5 kW or less: 0.01 A, 11 kW or greater: 0.1 A
n
E5-04: Number of Motor Poles (PM OLV)
Sets the number of motor poles.
No. Parameter Name Setting Range Default
E5-04 Number of Motor Poles (PM OLV) 2 to 48 Determined by E5-01
Note: The default value is determined by the motor code set to E5-01. This parameter is not reset when the drive is initialized using A1-03.
n
E5-05: Motor Armature Resistance (PM OLV)
Set the resistance for each motor phase in units of 0.001 W.
No. Parameter Name Setting Range Default
E5-05 Motor Armature Resistance (PM OLV) 0.000 to 65.000 Determined by E5-01
Note: The default value is determined by the motor code set to E5-01. This parameter is not reset when the drive is initialized using A1-03.
n
E5-06: Motor d Axis Inductance (PM OLV)
Sets the d axis inductance in units of 0.01 mH.
No. Parameter Name Setting Range Default
E5-06 Motor d Axis Inductance (PM OLV) 0.00 to 300.00 Determined by E5-01
Note: The default value is determined by the motor code set to E5-01. This parameter is not reset when the drive is initialized using A1-03.
n
E5-07: Motor q Axis Inductance (PM OLV)
Sets the q axis inductance in units of 0.01 mH.
No. Parameter Name Setting Range Default
E5-07 Motor q Axis Inductance (PM OLV) 0.00 to 600.00 Determined by E5-01
Note: The default value is determined by the motor code set to E5-01. This parameter is not reset when the drive is initialized using A1-03.
n
E5-09: Motor Induction Voltage Constant 1 (PM OLV)
Set the inductance voltage for each motor phase in units of 0.1 mV/(rad/min) [electrical angle]. Set this parameter when using an SSR1 series IPM motor
with derated torque or an SST4 series motor with constant torque.
n
E5-24: Motor Induction Voltage Parameter 2 (PM OLV)
Set the inductance voltage for each motor phase in units of 0.1 mV/(r/min) [mechanical angle]. Set this parameter when using an SMRA series pico motor.
Note: Ensure that E5-09 = 0 when setting parameter E5-24.
An alarm will be triggered, however, if both E5-09 and E5-24 are set 0, or if neither parameter is set to 0.
No. Parameter Name Setting Range Default
E5-09 Motor Induction Voltage Constant 1 (PM OLV) 0.0 to 2000.0 Determined by E5-01
E5-24 Motor Induction Voltage Parameter 2 (PM OLV) 0.0 to 2000.0 Determined by E5-01
Note: The default value is determined by the motor code set to E5-01. This parameter is not reset when the drive is initialized using A1-03.
5.5 E: Motor Parameters
154
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
