Item Specification
Three-Phase: CIMR-Vo2A
0030 0040 0056 0069
Single-Phase: CIMR-VoBA <1>
- - - -
Heat Generation (W)
Three Phase
ND Rating - - - -
HD Rating 335.3 379.5 509.7 646.2
Single Phase
ND Rating 303.7 321.3 465.2 589.1
HD Rating - - - -
<1> Drives with single-phase power supply inputs output three-phase power, and cannot run a single-phase motor.
<2> The motor capacity (kW) refers to a Yaskawa 4-pole motor. The rated output current of the drive output amps should be equal to or greater than the motor rated current.
<3> Input current rating varies depending on the power supply transformer, input reactor, wiring connections, and power supply impedance.
<4> Rated motor capacity is calculated with a rated output voltage of 220 V.
<5> Carrier frequency is set to 2 kHz. Current derating is required in order to raise the carrier frequency.
<7> Carrier frequency is set to 8 kHz. Current derating is required in order to raise the carrier frequency.
Note: Differences between HD ratings and ND ratings for the drive include rated input and output current, overload capacity, carrier frequency, current limit, and maximum output
frequency. Set parameter C6-01 to “O” for HD or “1” for ND (default).
A.2 Single/Three-Phase 200 V Class Drive
284
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
