No. Parameter Name
o2-04 Drive/kVA Selection
*Although the control method set to A1-02 is unaffected when performing a 2-wire or 3-wire initialization, the drive will automatically change A1-02
according to the value set to parameter A1-06.
Related Parameters
No. Parameter Name Setting Range Default Page
A1-01 Access Level Selection
0: Operation only
1: Preferred Parameters (access to a set of parameters selected by the user)
2: Advanced Access Level (A) and Setup Access Level (S)
2 -
A1-03 Initialize Parameter
0: No Initialize
1110: User Initialize
2220: 2-Wire Initialization
3330: 3-Wire Initialization
5550: oPE04 Reset
0 -
A2-01 to A2-32 Preferred Parameters 1 to 32 b1-01 to 02-08 Determined by A1-06 -
o2-03 User Parameter Default Value
Allows storing of parameter settings as a User Initialization Selection.
0: No Change
1: Set Defaults - Saves current parameter settings as user initialization.
2: Clear All - Clears the currently saved user initialization.
0 -
Application Presets
Below is a list of Application Presets and the settings automatically assigned to the parameters.
1: Water Supply Pump Application: Parameters and Settings
No. Name Optimum Setting
A1-02 Control Method Selection 0: Open Loop Vector
b1-04 Reverse Operation Selection 1: Reverse prohibited
C1-01 Acceleration Time 1 1.0 s
C1-02 Deceleration Time 1 1.0 s
C6-01 Duty Rating 1: Normal Duty
E1-03 V/f Pattern Selection 0FH
E1-07 Mid Output Frequency (FB) 30.0
E1-08 Mid Output Frequency Voltage (VC) 50.0
L2-01 Momentary Power Loss Operation Selection 1: Enabled
L3-04 Stall Prevention Selection during Deceleration 1: Enabled
Parameters below are automatically saved as Preferred Parameters (A2-01 to A2-16):
No. Parameter Name No. Parameter Name
b1-01 Frequency Reference Selection E1-08 Mid Output Frequency Voltage (VC)
b1-02 Run Command Selection E2-01 Motor Rated Current
b1-04 Reverse Operation Selection H1-05 Multi-Function Digital Input Terminal S5 Function Selection
C1-01 Acceleration Time 1 H1-06 Multi-Function Digital Input Terminal S6 Function Selection
C1-02 Deceleration Time 1 H1-07 Multi-Function Digital Input Terminal S7 Function Selection
E1-03 V/f Pattern Selection L5-01 Number of Auto Restart Attempts
E1-07 Mid Output Frequency (FB) − −
2: Conveyor Application Parameters and Settings
No. Parameter Name Optimum Setting
A1-02 Control Method Selection 0: Open Loop Vector
C1-01 Acceleration Time 1 3.0 s
C1-02 Deceleration Time 1 3.0 s
C6-01 Duty Rating 0: Heavy Duty
L3-04 Stall Prevention Selection during Deceleration 1: Enabled
Parameters below are automatically saved as Preferred Parameters (A2-01 to A2-16):
No. Parameter Name No. Parameter Name
A1-02 Control Method Selection C1-02 Deceleration Time 1
b1-01 Frequency Reference Selection E2-01 Motor Rated Current
b1-02 Run Command Selection L3-04 Stall Prevention Selection during Deceleration
C1-01 Acceleration Time 1 − −
3: Exhaust Fan Application: Parameters and Settings
No. Parameter Name Optimum Setting
A1-02 Control Method Selection 0: Open Loop Vector
b1-04 Reverse Operation Selection 1: Reverse Prohibited
C6-01 Duty Selection 1: Normal Duty
E1-03 V/f Pattern Selection 0FH
E1-07 Mid Output Frequency (FB) 30.0
E1-08 Mid Output Frequency Voltage (VC) 50.0
L2-01 Momentary Power Loss Operation Selection 1: Enabled
L3-04 Stall Prevention Selection during Deceleration 1: Enabled
Parameters below are automatically saved as Preferred Parameters (A2-01 to A2-16):
No. Parameter Name No. Parameter Name
b1-01 Frequency Reference Selection E1-07 Mid Output Frequency (FB)
5.1 A: Initialization
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
105
5
Parameter Details
