H6-01: (Terminal RP) Pulse Train Input Function Selection
Selects the function of pulse train (terminal RP).
This parameter selects the function of the pulse train terminal RP. If pulse train is to be used as the frequency reference (H6-01 = 0) parameter b1-01 must
be set to “4: Pulse Input.”
No. Parameter Name Setting Range Default
H6-01 (Terminal RP) Pulse Train Input Function Selection
0: Frequency reference
1: PID feedback value
2: PID setpoint value
3: Simple PG V/f control mode (can be set only when using motor 1 in the V/f control mode)
0
n
H6-02: Pulse Train Input Scaling
Pulse train input scaling parameter sets the number of pulses (in Hz) that is equal to the maximum output frequency E1-04.
No. Parameter Name Setting Range Default
H6-02 Pulse Train Input Scaling 1000 to 32000 1440 Hz
n
H6-03: Pulse Train Input Gain
Pulse train input gain sets the output level with the pulse train input is at 100% as a percentage of maximum output frequency (E1-04).
No. Parameter Name Setting Range Default
H6-03 Pulse Train Input Gain 0.0 to 1000.0 100.0%
n
H6-04: Pulse Train Input Bias
Pulse train input bias sets the output level when the pulse train input is 0 Hz as a percentage of maximum output frequency (E1-04).
No. Parameter Name Setting Range Default
H6-04 Pulse Train Input Bias -100.0 to 100.0 0.0%
n
H6-05: Pulse Train Input Filter Time
Sets the pulse train input filter time constant in seconds.
No. Parameter Name Setting Range Default
H6-05 Pulse Train Input Filter Time 0.00 to 2.00 0.10 s
n
H6-06: Pulse Train Input Monitor Selection
Selects the pulse train monitor output terminal MP function (value of the oo part of monitor U1-oo). See Appendix A for a complete list of monitors.
No. Parameter Name Setting Range Default
H6-06 Pulse Train Input Monitor Selection 000, 031, 101, 102, 105, 116, 501, 502, 801 to 809 102
n
H6-07: Pulse Train Input Monitor Scaling
Pulse train monitor scaling sets the number of output pulses when the monitor is 100% (in Hz). Set H6-06 to 102 and H6-07 to 0 to make the pulse train
monitor output synchronous to the output frequency.
No. Parameter Name Setting Range Default
H6-07 Pulse Train Input Monitor Scaling 0 to 32000 1440 Hz
5.7 H: Terminal Functions
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
185
5
Parameter Details
