The following simultaneous contradictory settings:H3-02 or H3-10 = B (PID Feedback) H6-01
(Pulse Train Input) = 1 (PID Feedback)
Disable one of the PID selections.
The following simultaneous contradictory settings: H3-02 or H3-10 = C (PID Target Value) H6-01
= 2 (pulse train input sets the PID target value)
The following simultaneous contradictory settings: H3-02 or H3-10 = C (PID Target Value) b5-18
= 1 (enables b5-19 as the target PID value)
The following simultaneous contradictory settings: H6-01 or H3-10 = C (PID Target Value) b5-18
= 1 (enables b5-19 as the target PID value)
LED Operator Display Error Name
oPE08
Parameter Selection Error
A function has been set that cannot be used in the motor control method selected.
Cause Possible Solutions
Attempted to use a function in the V/f motor control method that is only possible in Open Loop
Vector Control.
Check the motor control method and the functions available.
Simple V/f with PG was enabled while not in V/f Control (H6-01 = 3).
To use Simple V/f with PG, ensure the motor control method has been set to V/f Control (A1-02
= “0”).
In Open Loop Vector Control, n2-02 is greater than n2-03 Correct parameter settings so that n2-02 is less than n2-03.
In Open Loop Vector Control, C4-02 is greater than C4-06 Correct parameter settings so that C4-02 is less than C4-06.
In PM Open Loop Vector Control, parameters E5-02 to E5-07 are set to 0.
• Set the correct motor code in accordance with the motor being used (E5-01).
•
When using a special-purpose motor, set E5-oo in accordance with the Test Report provided.
The following conditions are true in PM Open Loop Vector Control:
• E5-03 does not equal 0
• E5-09 and E5-24 are both equal to 0, or neither equals 0
• Set E5-09 or E5-24 to the correct value, and set the other to “0”.
• Set the motor-rated current for PM to “0” (E5-03).
Note: Use U1-18 to find which parameters are set outside the specified setting range. Other errors are given precedence over OPE08 when multiple errors occur at the same time.
LED Operator Display Error Name
oPE09
PID Control Selection Fault
PID control function selection is incorrect. Requires that PID control is enabled (b5-01 = 1 to 4).
Cause Possible Solutions
The following simultaneous contradictory settings:
• b5-15 not 0.0 (PID Sleep Function Operation Level)
• The stopping method is set to either DC injection braking or coast to stop with a timer (b1-03
= 2 or 3).
• Set b5-15 to another value besides 0.
• Set the stopping method to coast to stop or ramp to stop (b1-03 = “0” or “1”).
LED Operator Display Error Name
oPE10
V/f Data Setting Error
The following setting errors have occurred where: E1-04 is greater than or equal to E1-06 is greater
than or equal to E1-07 is greater than or equal to E1-09.
Or the following setting errors have occurred: E3-04 is greater than or equal to E3-06 is greater
than or equal to E3-07 is greater than or equal to E3-09.
Cause Possible Solutions
— Correct the settings for E1-04, -06, -07 and -09 (or E-04, -06, -07, -09 for motor 2).
LED Operator Display Error Name
oPE11
Carrier Frequency Setting Error
Correct the setting for the carrier frequency.
Cause Possible Solutions
The following simultaneous contradictory settings: C6-05 is greater than 6 and C6-04 is greater
than C6-03 (carrier frequency lower limit is greater than the upper limit). If C6-05 is less than or
equal to 6, the drive operates at C6-03.
Correct the parameter settings.
Upper and lower limits between C6-02 and C6-05 contradict each other.
LED Operator Display Error Name
oPE13
Pulse Monitor Selection Error
Incorrect setting of monitor selection for Pulse Train (H6-06).
Cause Possible Solutions
Scaling for the Pulse Train monitor is set to 0
(H6-07 = 0) while H6-06 is not set to 101, 102,
105, or 116.
Change scaling for the Pulse Train monitor or set H6-06 to 101, 102, 105, or 116.
