YASKAWA V1000 Series Technical Manual

No. Name Description Range Def.
Control Mode
Addr.
Hex
Pg.
V/f
OL
V
PM
F6 and F7: Serial Communications Option Card Settings
Use F6 parameters to program the drive for serial communication.
F6-01
Communications Error operation
Selection
Selects the operation after a communications error occurred.
0: Ramp to stop using current accel/decel time
1: Coast to stop
2: Fast Stop using C1-09
3: Alarm only
0 to 3 1 A A A 3A2
F6-02
External fault from comm. option
selection
Sets when an external fault from a comm option is detected.
0: Always detected
1: Detection during Run only
0 or 1 0 A A A 3A3
F6-03
External fault from comm. option
operation selection
Selects the operation after an external fault set by a communications option
(EF0).
0: Ramp to stop using current accel/decel time
1: Coast to stop
2: Fast Stop using C1-09
3: Alarm only
0 to 3 1 A A A 3A4
F6-04 Trace Sampling Rate - 0.0 to 5.0 2.0 s A A A 3A5
F6-10 CC-Link Node Address Sets the node address if a CC-Link option card is installed 0 to 63 0 A A A 3E6
F6-11 CC-Link communications speed
0: 156 Kbps
1: 625 Kbps
2: 2.5 Mbps
3: 5 Mbps
4: 10 Mbps
0 to 4 0 A A A 3E7
F6-14 BUS Error auto reset Selects if a BUS fault can be automatically reset. 0 or 1 0 A A A 3BB
F6-20 DeviceNet MAC Address Selects the drive’s MAC address for DeviceNet. 0 to 63 0 A A A 3C1
F6-21 Device Net Communications Speed
0: 125 kbps
1: 250 kbps
2: 500 kbps
3: Detect automatically
0 to 3 3 A A A 3C2
F6-22 Device Net PCA setting I/O Polled Consuming Assembly Data Instance 0 to 255 0 A A A 3C3
F6-23 Device Net PPA setting I/O Polled Producing Assembly Data Instance 0 to 255 0 A A A 3C4
F6-24 Device Net Idle mode fault detection
Selects if a fault s is detected during communication idle mode.
0: Disabled
1: Enabled
0 or 1 0 A A A 3C5
F6-30 Profibus node address Sets the node address for a Profibus option. 0 to 125 0 A A A 3CB
F6-31 Profibus Clear mode selection
Selects the operation when a "Clear Mode" command is received.
0: Resets back to zero.
1: Maintains the previous value.
0 or 1 0 A A A 3CC
F6-32 Profibus Map selections
0: PPO Type
1: Conventional
0 or 1 0 A A A 3CD
F6-36 CANopen Node ID selection Sets the Node ID for a CANopen option 0 to 127 99 A A A 3D0
F6-37 CANopen Communications speed
0: Auto-adjust
1: 10 kbps
2: 20 kbps
3: 50 kbps
4: 125 kbps
5: 250 kbps
6: 500 kbps
7: 800 kbps
8: 1 Mbps
0 to 8 6 A A A 3D1
F6-40 CompoNet Node ID Sets the Node ID for a CompoNet option. 0 to 63 0 A A A 3D5
F6-41 CompoNet Speed
0: 93.75kbit/s
1: Reserved
2: 1.5Mbit/s
3: 3Mbit/s
4: 4Mbit/s
5-255: Reserved
0 to 255 0 A A A 3D6
F7-01 Ethernet IP Address 1
Combining these parameters like F7-01.F7-02.F7-03.F7-04 sets the Ethernet IP
address. Example: (192.168.1.10)
0 to 255 0 A A A 3E5
F7-02 Ethernet IP Address 1 0 to 255 0 A A A 3E6
F7-03 Ethernet IP Address 1 0 to 255 0 A A A 3E7
F7-04 Ethernet IP Address 1 0 to 255 0 A A A 3E8
F7-05 Subnet Mask 1
Combining these parameters like F7-05.F7-06.F7-07.F7-08 sets the Ethernet
Subnet Mask. Example: (255.255.255.0)
0 to 255 0 A A A 3E9
F7-06 Subnet Mask 2 0 to 255 0 A A A 3EA
F7-07 Subnet Mask 3 0 to 255 0 A A A 3EB
F7-08 Subnet Mask 4 0 to 255 0 A A A 3EC
F7-09 Gateway Address 1
Combining these parameters like F7-09.F7-10.F7-11.F7-12 sets the Ethernet
Gateway Address. Example: (192.168.1.1)
0 to 255 0 A A A 3ED
F7-10 Gateway Address 2 0 to 255 0 A A A 3EE
F7-11 Gateway Address 3 0 to 255 0 A A A 3EF
F7-12 Gateway Address 4 0 to 255 0 A A A 3F0
F7-13 Dress Mode at Startup
Selects how the Ethernet IP address is set.
0: User defined
1: BOOTP
2: DHCP
0 to 2 0 A A A 3F1
F7-14 Security password
Sets the password required for setup changes via the network.
0: No password required
1 - 9999: 4 digit password
0 to 9999 0 A A A 3F2
F7-15 Duplex Mode Selection
0: Auto Negotiate
1: Half Duplex forced
2: Full Duplex forced
0 to 2 0 A A A 3F3
F7-18 Communication Speed Selection
0: Auto Negotiate
10: 10 Mbps speed setting
100: 100Mbps Speed Setting
0, 10, 100 0 A A A 3F6
B.2 Parameter Table
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
305
B
Parameter List

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
