289
Use the Program field in the upper-left corner to select the program whose pads you want to view. Remember that
only drum programs, keygroup programs, or clip programs will display properly in the Pad Mixer.
Use the Track field at the top of the screen to select the desired track.
The time counter in the upper-right corner the current playhead position. This is shown in most of the modes. See
General Features > Time Counter/Locate to learn about this.
The automation button indicates the global automation state. This is shown in several modes. See General
Features > Automation to learn about this.
To view a specific setting on all channels, tap the Level, Pan, Mute, Send, Insert, or Route button at the bottom
of the screen. You can tap the Send or Insert buttons multiple times to cycle through the four available slots for each.
When a pad is selected, you can view and adjust all of its settings in the left side of
the screen rather than using the tab buttons at the bottom.
When viewing the channel strip:
The first field shows the current pad number. Press a pad or double-tap the
field to select a different pad.
The second field shows where the pad is routed, which you can change:
Program (the usual setting); Out 1,2–7,8, Out 1–8 or Sub 1–8 in Standalone
Mode; and Out 1,2–31,32 or Out 1–32 in Controller Mode.
Note: When set to a mono channel, the left and right channels are summed
post-pan knob. If the pan knob is set to the center position, the left and right
channels will be summed and padded. If the pan knob is set to the maximum
left or right positions, only the respective channel will be sent to the output.
The Inserts field shows any enabled or disabled effects for that pad. Tap the
area under Inserts to open a window where you can load, change, and enable
or disable the effects.
Tap Solo or Mute to solo or mute the pad (respectively).
Adjust the pan knob or level slider to change the panning or level of the pad.
