393
MPC Touch
Line Inputs
(2) balanced
1/4” (6.35 mm) TRS
Dynamic Range
102 dB
(A-weighted)
SNR
99 dB
(1 kHz, +4 dBu, A-weighted)
THD+N
0.002%
(1 kHz, +4 dBu, -1 dBFS)
Frequency Response
20 Hz – 20 kHz
(+0.1 / -0.1 dB)
Maximum Input Level
+15 dBu
Input Impedance
12 KΩ
(balanced), 5 KΩ (unbalanced)
Sensitivity
-16 dBu
Gain Range
31 dB
Main Outputs
(2) impedance-
balanced 1/4”
(6.35 mm) TRS
Dynamic Range
100 dB
(A-weighted)
THD+N
0.006%
(1 kHz, -1 dBFS)
Frequency Response
20 Hz – 20 kHz
(+0.25 / -0.25 dB)
Maximum Output Level
+8 dBu
Output Impedance
100 Ω
Headphone Output
(1) 1/8” (3.5 mm)
stereo headphone
THD+N
0.009%
(1 kHz, -1 dBFS, 10 mW/channel into 32 Ω headphones)
Frequency Response
20 Hz – 20 kHz
(+0.3 / -0.3 dB)
Maximum Output Level
+6 dBu
Maximum Power Delivered
12 mW/channel
Output Impedance
33 Ω
Mechanical Pads
(16) velocity- and pressure-sensitive pads, RGB-backlit
(8) banks accessible via Pad Bank buttons
Knobs
(4) 360° touch-sensitive Q-Link knobs
(4) Q-Link knob columns accessible via Q-Link button
(1) 360° encoder for value/data adjustment and selection via push
Display
7.0” (17.8 cm) full-color 1280
x800 display with capacitive
multi-touch
Connections
(2) 1/4” (6.35 mm) TRS inputs
(1 stereo pair)
(2) 1/4” (6.35 mm) TRS outputs
(1 stereo pair)
(1) 1/8” (3.5 mm) stereo headphone output
(1) 1/8” (3.5 mm) MIDI input
(1/8”-to-5-pin adapter included)
(1) 1/8” (3.5 mm) MIDI output
(1/8”-to-5-pin adapter included)
(1) USB Type-B port
(1) power adapter input
Power
via power adapter: 6 VDC, 3 A, center-positive, included
Dimensions
(width x depth x height)
16.2” x 8.6” x 1.9”
41.1 x 21.8 x 4.8 cm
Weight
4.6 lb.
2.1 k
