120
Programs
You can load up to four insert effects to each program. You can do this in Main Mode, XYFX Mode, and the Channel
Mixer.
Note: In XYFX Mode, the effects act like a single insert effect on that program. In fact, XYFX is the name of the insert
effect that is loaded when use this mode.
To load a program insert effect in Main Mode:
1. When the MIDI tab is selected (in the lower-left corner), use the Track field to select the track that uses the
program with the desired pad—the program it uses will be selected automatically.
2. If the channel strip is not already shown, tap the small eye icon below the Project field to show it.
3. Tap the four-pads icon at the top of the channel strip. The channel strip will now show settings for the current
program.
4. Tap the area under Inserts, and then use the screen that appears to load or edit effects.
