Akai MPC Live User Manual

390
MPC Key 37
Digital Audio System ADCs
24-bit @ 44.1, 48, or 96 kHz
DACs
24-bit @ 44.1, 48, or 96 kHz
Digital Signal
Processing
32-bit floating point
Line Inputs 1–2
(2) balanced 1/4” (6.35 mm)
TRS or unbalanced 1/4”
(6.35 mm) TS
Frequency Response
20 Hz – 20 kHz (+0.2/-0.5 dB)
Signal-to-Noise Ratio
107 dB (1 kHz, +6 dBV, A-weighted)
THD+N
0.004% (1 kHz, +6 dBV, 0 dBFS)
Max Input Level
+12 dBV
Sensitivity
-10 dBV
Gain Range
27 dB
Line Outputs 1–2
(2) impedance-balanced
1/4” (6.35 mm) TRS
Frequency Response
20 Hz – 20 kHz (+0.2/-0.5 dB)
Dynamic Range
112 dB (A-weighted)
THD+N
0.004% (1 kHz, 0 dBFS)
Maximum Output Level
+6 dBV
Output Impedance
100 Ω
Headphone Output
(1) 1/8” (3.5 mm)
stereo headphone
Frequency Response
20 Hz – 20 kHz (+0.2/-0.5 dB)
Dynamic Range
112 dB (A-weighted)
THD+N
0.006% (1 kHz, 10mW per channel into 32Ω)
Maximum Output Level
40 mW RMS (per channel into 32Ω)
Mechanical Keys
37 synth-action keys with aftertouch
Pads
(16) velocity- and pressure-sensitive pads, RGB-backlit
(8) banks accessible via Pad Bank buttons
Knobs
(4) 360° touch-sensitive Q-Link knobs
(4) Q-Link Knob columns accessible via Q-Link button
(1) 360° encoder for value/data adjustment
Buttons
(38) dedicated function buttons; white-, red-, or green-
backlit
Display
7” / 177 mm (diagonal)
Full-color LED-backlit display with touch interface
Memory RAM
2 GB
Internal Storage
32 GB

Akai MPC Live Specifications

General

Built-in display	Yes
Mixer section	-
Product color	Black
Number of drum pads	16
Built-in optical drive	No
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	2
Headphone outputs	1
USB connector type	USB Type-A, USB Type-B
USB ports quantity	3
Headphone connectivity	3.5 mm
Cables included	USB

Weight and Dimensions

Depth	223 mm
Width	410 mm
Height	67.5 mm
Weight	2721.55 g
