351
Mother Ducker Input
Add this effect as an insert to the track you want to use as a
trigger input, such as a kick drum track.
Parameter Value Range Default Value
To Bus 1–8 Bus 1
Mother Ducker
Add this effect as an insert to the track you want to have the
ducking effect applied to. Use the meters to monitor the
level from your trigger input and tweak the Threshold and
Ratio parameters to adjust the amount of ducking. The
Attack and Release parameters can be used to sculpt the
envelope of the gain reduction to achieve exactly the
pumping effect you are after. Mother Ducker has eight
internal buses so you can set up multiple channel strips with
ducking effects from different sources.
Parameter Value Range Default Value
Ratio 1.00:1 – 60.00:1 6.00:1
Knee 0.000 – 6.000 dB 0.000 dB
ttack 1.0 – 1000.0 ms 10.0 ms
Release 1.0 – 1000.0 ms 100.0 ms
Threshold -100.000 – 0.000 dB -6.021 dB
Gain -100.000 – +12.000 dB -0.000 dB
uto Gain On, Off On
From Bus 1–8 Bus 1
Transient Shaper
A transient shaper can be used to enhance or soften the
Attack and Release phases of audio material.
Parameter Value Range Default Value
Dry/Wet 0–100 (dry–wet) 100
Attack 0–100 50
Release 0–100 50
Output 0–100 50
EQ/Filter
Options: Options: AIR Enhancer, AIR Filter Gate, AIR Filter, AIR Kill EQ, AIR Para EQ, AIR Vintage Filter*, HP
Filter Sweep, HP Filter Sync, HP Filter, HP Shelving Filter, LP Filter Sweep, LP Filter Sync, LP Filter, LP
Shelving Filter, PEQ 2-Band, 2-Shelf, PEQ 4-Band
AIR Enhancer
This effect enhances the low and high
broadband frequencies of the audio signal.
Parameter Value Range Default Value
Hi
h Gain 0.0 – 12.0 dB 0.0 dB
Low Gain 0.0 – 12.0 dB 0.0 dB
Output - Inf – 0.0 dB 0.0 dB
Freq. Hi
h 1.0 – 10.0 kHz 3.16 kHz
Freq. Low 40.0 – 640 Hz 160 Hz
Harmonics 0.0 – 12.0 dB 0.0 dB
Phase + (positive), - (ne
ative) +
