Buttons
Buttons usually have two states: selected and deselected (active or inactive, respectively).
Some may have more than two states.
To switch between or cycle through a button’s states, do either of the following:
• Tap it.
• If it is outlined in red (and is not a mute button), use the data dial or –/+ buttons.
Checkboxes
Checkboxes have two states: checked and unchecked (enabled or disabled, respectively).
To check or uncheck a checkbox, tap it.
Tabs
Some modes have buttons at the bottom of the screen that let you cycle through several
similar tabs. For instance, you could view the send level that is routed to each of four
returns—each level is shown on a separate tab. With each tap, you will move to the next
tab, indicated by the squares below it.
To select a tab, tap it. Each time you tap it, it will select the next tab.
Sliders
To adjust the position of a slider, do any of the following:
• Tap and drag the slider to the desired position.
• Tap the desired position (this works only on some sliders).
• Tap the slider to select it, and then use the data dial or –/+ buttons to adjust the position (this works only on
some sliders).
• Double-tap the slider, and then tap and drag the larger version that appears, or use the data dial or –/+ buttons
to adjust the value. If the slider controls a volume level, double-tap the larger version to reset it to 0 dB. Tap
anywhere else to return to the previous screen.
